featuring TVJNR/L-TB T-HOLDERS WITH HIGH-PRESSURE COOLANT (VN_ X2.53X INSERT) HBKW WF B 44° max. 93° LF LH HF H HBH 1/8-27 NPTF Dimension (inch) Approach angle Part Number H HF B LF WF LH HBH HBKW Insert Shank Functional Shank Functional Functional Head Head Bottom Head Back Height Height Width Length Width Length Offset Height Offset Width 93° TVJNR/L 12-2.53B-TB .750 .750 .750 4.5 1.000 1.73 .31 .256 B 44° max. TVJNR/L 16-2.53D-TB 1.000 1.000 1.000 6.0 1.250 1.73 .25 - VN... X2.53... TVJNR/L 20-2.53D-TB 1.250 1.250 1.250 6.0 1.500 1.73 - - H TF Spare Parts Clamp Clamp Screw Spring UpperO-ring LowerO-ring Shim ShimScrew Wrench Part Number TVJNR/L-TB DLM 2.5V-NX-TB BH M5x0.8x25-TB DSP 4 O-RING ID5.28x O-RING ID7.59x1.782.62MSVI2.522 SO 40085I L-W 3 T 15 140
