r B φDcR1.2 φDb Tooling by DIJET QM MAX G II MXGTYPE MXG Through coolant hole TY PE W C MD 1.7 Lf ■ BODY Dimensions (mm) Parts Cat No. No.StockofinsertsφDcLfφDb MD C W ApplicableInserts ClampScrew Wrench MXG-2016-M8 ● 2 16 23 14 M8 8 12 MXG-2017-M8 ● 2 17 23 14 M8 8 12 MXG-3020-M10 ● 3 20 30 18 M10 9 14 MXG-3021-M10 ● 3 21 30 18 M10 9 14 MXG-3025-M12 ● 3 25 35 22 M12 11 19 MXG-4025-M12 ● 4 25 35 22 M12 11 19 ENMU100412ZER-PH TSW-2567H A-08 MXG-4026-M12 ● 4 26 35 22.5 M12 11 19 MXG-5030-M16 ● 5 30 43 27 M16 12 22 MXG-5032-M16 ● 5 32 43 29 M16 12 22 MXG-5035M16 ● 5 35 43 29 M16 12 22 MXG-6040-M16 ● 6 40 43 32 M16 14 26 MXG-6042-M16 ● 6 42 43 32 M16 14 26 Note) 1. All cutters are supplied without inserts. Arbor B193 2. Please see page B009 for recommended tightening torque. Clamp Screw Recommended Torque(N・m) MXG TSW-2567H 1.1 TY PE ■ Inserts -PH A T Dimensions (mm) PVD coated Cat. No. Tole-ranceA T B rε JC8118 JC7560 ENMU100412ZER-PH M 10 4 6 1.2 ● ● 10 inserts per case B080 ● Standard stock items
