Каталог ARNO монолитный осевой инструмент - страница 94

AFA d dA TiCN l VHM-Schruppfräser AFA Solid carbide roughing end-mill Fraise carbure monobloc d‘ébauche AFA51431-… 3 Schneiden, lange Ausführung / 3 flutes, long design / 3 dents, version longue HA 98 – 106 30° 3 Feinstkorn Ultra micro granulation Grain ultra fin l1 PG 24 beschichtet coated revêtu Schaft DIN 6535HA Shank d dA l1 l Tige js12 h6 AFA51431-060 6 6 16 57  AFA51431-070 7 8 16 63  AFA51431-080 8 8 16 63  AFA51431-090 9 10 19 72  AFA51431-100 10 10 22 72  AFA51431-120 12 12 26 83  AFA51431-140 14 14 26 83  AFA51431-160 16 16 32 92  AFA51431-180 18 18 32 92  AFA51431-200 20 20 38 104  AFA51431-250 25 25 45 121    Hauptanwendung Main application Application principale  Nebenanwendung Secondary application Application secondaire 94 VHM- / PM-HSS Werkzeuge | Solid carbide- / PM-HSS Tools | Outils carbure monobloc / PM-HSS Alle Angaben in mm / Dimensions in mm / Toutes les dimensions en mm
