Verwendung: Zum Längsdrehen von Drehteilen.
Application: For longitudinal turning.
Application: Pour le tournage á surfacer en longueur.
PCRNR / L Kr = 75°
S
K r l
D
| ISO 26623 CAD | |||||
| Bestell-Nr. Order no. / Référence | D | l1 | S | WSP Insert / Plaquette | Lager Stock |
| PSC50.PCRNR2706012 | 50 | 60 | 27 | CN..1204.. | |
| PSC50.PCRNL2706012 | 50 | 60 | 27 | CN..1204.. | |
| PSC63.PCRNR3506512 | 63 | 65 | 35 | CN..1204.. | |
| PSC63.PCRNL3506512 | 63 | 65 | 35 | CN..1204.. | |
| PSC50.PCRNR2706016 | 50 | 60 | 27 | CN..1606.. | |
| PSC50.PCRNL2706016 | 50 | 60 | 27 | CN..1606.. | |
| PSC63.PCRNR3506516 | 63 | 65 | 35 | CN..1606.. | |
| PSC63.PCRNL3506516 | 63 | 65 | 35 | CN..1606.. | |
| PSC50.PCRNR2706019 | 50 | 60 | 27 | CN..1906.. | |
| PSC50.PCRNL2706019 | 50 | 60 | 27 | CN..1906.. | |
| PSC63.PCRNR3506519 | 63 | 65 | 35 | CN..1906.. | |
| PSC63.PCRNL3506519 | 63 | 65 | 35 | CN..1906.. | |
| PSC80.PCRNR4508019 | 80 | 80 | 45 | CN..1906.. | |
| PSC80.PCRNL4508019 | 80 | 80 | 45 | CN..1906.. |
e
Hinweis: Linker Drehhalter gezeigt, sofern nicht anders angegeben.
Note: Left hand style shown unless otherwise stated.
Observation: Outil de tournage à gauche comme sur la photo.
