General Turning /Allgemeine Drehbearbeitung, ISO Kennzeichnung
Milling · Fräsen
Solid Carbide end mills · Vollhartmetallschaftfräser

2-flute ball nose end mills with straight shank and long cutting edge
2-Schneiden Kugelkopffräser mit langer Schneide und Zylinderschaft
PM-2BL
A


B

Coated D≤12 0~-0.020
30o D R R±0.01
Nano-AITiN 12<D 0~-0.030

Dimension(mm) Grade
Type Abmessungen Teeth Geometry
Typ
Zähne Ausführung Sorte
D R d H L Z KMG 405
PM-2BL-R1.0 2.0 1.0 6 4 75 2 A ●

B
PM-2BL-R1.25 2.5 1.25 6 5 75 2 A ●
PM-2BL-R1.5 3.0 1.5 6 6 75 2 A ●
PM-2BL-R1.75 3.5 1.75 6 8 75 2 A ●
PM-2BL-R2.0 4.0 2.0 6 8 75 2 A ●
PM-2BL-R2.5 5.0 2.5 6 10 75 2 A ●
PM-2BL-R2.75 5.5 2.75 6 12 75 2 A ●
PM-2BL-R3.0 6.0 3.0 6 12 75 2 B ●
Vollhartmetallschaftfräser


PM-2BL-R3.5 7.0 3.5 8 14 75 2 A ●
Solid Carbide end mills


PM-2BL-R4.0 8.0 4.0 8 16 100 2 B ●
PM-2BL-R4.5 9.0 4.5 10 18 100 2 A ●
PM-2BL-R5.0 10.0 5.0 10 20 100 2 B ●
PM-2BL-R6.0 12.0 6.0 12 24 100 2 B ●
PM-2BL-R7.0 14.0 7.0 14 28 100 2 B ●
PM-2BL-R8.0 16.0 8.0 16 32 150 2 B ●
PM-2BL-R10.0 20.0 10.0 20 40 150 2 B ●


= Very suitable · Sehr empfohlen
Material Overview · Material Übersicht = Suitable · Empfohlen
Workpiece material
KMG405


Werkstückstoff
Quenched and
Hardened steel ·
tempered steel · Cast iron,
Gehärteter Stahl Stainless Heat resist
Carbon steel Alloy steel Vergüteter Stahl Nodular Copper Aluminum Titanium
steel · alloy
Kohlenstoff Legierter cast iron alloy alloy alloy
Rostfreier warmfeste
Stahl Stahl Grauguss Kupfer Leg Alu Leg Titan Leg
~40HRC ~50HRC ~55HRC ~68HRC Stahl Leg
GGG

        
● Ex Stock / ab Lager ○ On demand / auf Anfrage
B 280
