Каталог ZCC-CT фрезы монолитные - страница 289
Навигация
Каталог ZCC-CT оснастка
Каталог ZCC-CT фрезы со сменными пластинами
Каталог ZCC-CT сверла со сменными пластинами
Каталог ZCC-CT токарная обработка
Каталог ZCC-CT сверла монолитные
Deburring Cutter 90°
Entgratfräser 90°
5501/5601
S D X
Z=teeth Zähne L
| Coating Coated | |||||||
| Article no. Atikl N | D | imension (m Abmessung | m) | Shank Shft | |||
| re r. | D | L | S | Z | X | ca | Grade /SorteKMG 303 |
| 5501R903FM-0300 | 3 | 48 | 2.1 | 3 | 90 | HA | ● |
| 5501R904FM-0400 | 4 | 48 | 2.8 | 4 | 90 | HA | ● |
| 5601R904FM-0600 | 6 | 55 | 4.2 | 4 | 90 | HB | ● |
| 5601R904FM-0800 | 8 | 58 | 5.6 | 4 | 90 | HB | ● |
| 5601R904FM-1000 | 10 | 65 | 7.0 | 4 | 90 | HB | ● |
| 5601R904FM-1200 | 12 | 75 | 8.5 | 4 | 90 | HB | ● |
| 5601R904FM-1600 | 16 | 85 | 11.3 | 4 | 90 | HB | ● |
Deburring Cutter 60°
Entgratfräser 60°
5501/5601
| D | S X | |||||
| Coating Coated | Z=teeth Zähne | L | ||||
| Article no. Artikel Nr. | Di | mension (mm Abmessung | ) | Shank Schaft | ||
| D | L | S | Z X | Grade /SorteKMG 303 | ||
| 5501R603FM-0300 | 3 | 48 | 3 | 3 60 | HA | ● |
| 5501R604FM-0400 | 4 | 48 | 4 | 4 60 | HA | ● |
| 5601R604FM-0600 | 6 | 55 | 6 | 4 60 | HB | ● |
| 5601R604FM-0800 | 8 | 58 | 8 | 4 60 | HB | ● |
| 5601R604FM-1000 | 10 | 65 | 10 | 4 60 | HB | ● |
| 5601R604FM-1200 | 12 | 75 | 12 | 4 60 | HB | ● |
| 5601R604FM-1600 | 16 | 85 | 16 | 4 60 | HB | ● |
