HM-6EL series for machining high hardness steel · HM-6EL Serie für die Hartbearbeitung
6-flute end mills with straight shank and long cutting edges
6- Schneiden Schaftfräser mit Zylinderschaft und langer Schneide
H L
| 45 o Coa Nano- | D 1 D ted AITiN | ≤12 0~-0.020 2 | ||||
| Type | Dime Abm | nsion(mm) essungen | Teeth Zähne | Grade Sorte | ||
| Typ | D | d | H | L | Z | KMG 555 |
| HM-6EL-D6.0 | 6.0 | 6 | 24 | 75 | 6 | ● |
| HM-6EL-D8.0 | 8.0 | 8 | 32 | 75 | 6 | ● |
| HM-6EL-D10.0 | 10.0 | 10 | 40 | 100 | 6 | ● |
| HM-6EL-D12.0 | 12.0 | 12 | 45 | 100 | 6 | ● |
| HM-6EL-D16.0 | 16.0 | 16 | 64 | 150 | 6 | ● |
| HM-6EL-D20.0 | 20.0 | 20 | 75 | 150 | 6 | ● |
= Very suitable · Sehr empfohlen
Material Overview · Material Übersicht = Suitable · Empfohlen
| Carbon steel Kohlenstoff Stahl | Alloy steel Legierter Stahl | Quench tempere ~40HRC Vergütet | ed and d steel · ~50HRC er Stahl | Hardene ~60HRC Gehärte | Workpiece d steel · ~68HRC Werkstü ter Stahl | material Stainless steel · ckstoff Rostfreier Stahl | Cast iron, Nodular cast iron Grauguss GGG | Copper alloy Kupfer Leg | Aluminum alloy Alu Leg | Titanium alloy Titan Leg | Heat resist alloy warmfeste Leg |
| | | | |
