DIN 6527L Roughing end mills · DIN 6527L VHM Schruppfräser
5602R303/304/305GR
KMG303: nano AlTiN coated Ultra-fine carbide / nano AlTiN beschichtetes Ultrafeinkornhartmetall
BB
| Type | Dimension(mm) | Teeth | Application | S | ||||
| Abmessungen | Zähne | Anwendung | ||||||
| Typ | ||||||||
| d1(e8) | d2(h6) | l2 | l1 | z | Grade | KMG303 | ||
| Sorte | ||||||||
| 5602R303GR-0600 | 6.00 | 6 | 13 | 57 | 3 | ● | ||
| 5602R303GR-0800 | 8.00 | 8 | 19 | 63 | 3 | ● | ||
| 5602R304GR-1000 | 10.00 | 10 | 22 | 72 | 4 | ● | ||
| 5602R304GR-1200 | 12.00 | 12 | 26 | 83 | 4 | ● | ||
| 5602R304GR-14005602R304GR-1400 | 1414.00 | 1414 | 3030 | 9090 | 44 | ○ | ||
| 5602R304GR-1600 | 16.00 | 16 | 32 | 92 | 4 | ● | ||
| 5602R304GR-2000 | 20.00 | 20 | 38 | 104 | 4 | ● | ||
| 5602R304GR-14005602R305GR-2500 | 1425.00 | 1425 | 3045 | 90121 | 45 | ○ | ||
| 5602R305GR-2500 | 25 | 25 | 45Art. Group No. / 121 Produktgruppe Nr. :5 | 021130 |
= Very suitable · Sehr empfohlen
Material Overview · Material Übersicht = Suitable · Empfohlen
| 3 | Workpiece Werkstü | material ckstoff | ||||||||||
| KMG30 | Carbon steel Kohlenstoff Stahl | Alloy steel Legierter Stahl | Quench tempere ~40HRC Vergütet | ed and d steel · ~50HRC er Stahl | Hardene ~55HRC Gehärtet | d steel · ~68HRC er Stahl | Stainless steel · Rostfreier Stahl | Cast iron, Nodular cast iron Grauguss GGG | Copper alloy Kupfer Leg | Aluminum alloy Alu Leg | Titanium alloy Titan Leg | Heat resist alloy warmfeste Leg |
| | | | | | | |
