| EG(STI) UNC | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( inch ) | THL ( inch ) | LU ( inch ) | LS ( inch ) | DCON ( inch ) | K ( inch ) | LK ( inch ) | N | OF | Type | Stock | Intro |
| ANSI | |||||||||||||||||
| GH1 | 2.35 | 2.4 | TUUN2E1NEB5 | 5P | 2.205 | 0.354 | 0.709 | 1.28 | 0.14 | 0.11 | 0.187 | 3 | 005 | f | |||
| STI N256UNC | GH1 | 2.35 | 2.4 | TUUN2E1NEBA | 1.5P | 2.205 | 0.354 | 0.709 | 1.28 | 0.14 | 0.11 | 0.187 | 3 | 005 | f | SP | |
| o.- | GH2 | 2.35 | 2.4 | TUUN2E2NEB5 | 5P | 2.205 | 0.354 | 0.709 | 1.28 | 0.14 | 0.11 | 0.187 | 3 | 005 | f | ||
| GH2 | 2.35 | 2.4 | TUUN2E2NEBA | 1.5P | 2.205 | 0.354 | 0.709 | 1.28 | 0.14 | 0.11 | 0.187 | 3 | 005 | f | |||
| GH1 | 3.1 | 3.13 | TUUN4H1NEB5 | 5P | 2.48 | 0.512 | 0.827 | 1.496 | 0.17 | 0.131 | 0.25 | 3 | 005 | f | |||
| STI N4-40UNC | GH1 | 3.1 | 3.13 | TUUN4H1NEBA | 1.5P | 2.48 | 0.512 | 0.827 | 1.496 | 0.17 | 0.131 | 0.25 | 3 | 005 | f | SL | |
| o. | GH2 | 3.1 | 3.13 | TUUN4H2NEB5 | 5P | 2.48 | 0.512 | 0.827 | 1.496 | 0.17 | 0.131 | 0.25 | 3 | 005 | f | ||
| GH2 | 3.1 | 3.13 | TUUN4H2NEBA | 1.5P | 2.48 | 0.512 | 0.827 | 1.496 | 0.17 | 0.131 | 0.25 | 3 | 005 | f | |||
| GH1 | 3.8 | 3.83 | TUUN6J1NEB5 | 5P | 2.756 | 0.551 | 0.945 | 1.654 | 0.19 | 0.131 | 0.25 | 3 | 005 | f | PO | ||
| STI N632UNC | GH1 | 3.8 | 3.83 | TUUN6J1NEBA | 1.5P | 2.756 | 0.551 | 0.945 | 1.654 | 0.19 | 0.131 | 0.25 | 3 | 005 | f | ||
| o.- | GH2 | 3.8 | 3.83 | TUUN6J2NEB5 | 5P | 2.756 | 0.551 | 0.945 | 1.654 | 0.19 | 0.131 | 0.25 | 3 | 005 | f | ||
| GH2 | 3.8 | 3.83 | TUUN6J2NEBA | 1.5P | 2.756 | 0.551 | 0.945 | 1.654 | 0.19 | 0.131 | 0.25 | 3 | 005 | f | |||
| GH1 | 4.4 | 4.48 | TUUN8J1NEB5 | 5P | 3.15 | 0.591 | 0.984 | 1.929 | 0.22 | 0.165 | 0.281 | 3 | 005 | f | ST | ||
| STI No8-32UNC | GH1 | 4.4 | 4.48 | TUUN8J1NEBA | 1.5P | 3.15 | 0.591 | 0.984 | 1.929 | 0.22 | 0.165 | 0.281 | 3 | 005 | f | ||
| . | GH2 | 4.4 | 4.48 | TUUN8J2NEB5 | 5P | 3.15 | 0.591 | 0.984 | 1.929 | 0.22 | 0.165 | 0.281 | 3 | 005 | f | ||
| GH2 | 4.4 | 4.48 | TUUN8J2NEBA | 1.5P | 3.15 | 0.591 | 0.984 | 1.929 | 0.22 | 0.165 | 0.281 | 3 | 005 | f | |||
| GH2 | 5.2 | 5.23 | TUUNAM2NEB5 | 5P | 3.15 | 0.591 | 1.181 | 1.713 | 0.26 | 0.191 | 0.312 | 3 | 005 | f | ROLL | ||
| STI No10-24UNC | GH2 | 5.2 | 5.23 | TUUNAM2NEBA | 1.5P | 3.15 | 0.591 | 1.181 | 1.713 | 0.26 | 0.191 | 0.312 | 3 | 005 | f | ||
| . | GH3 | 5.2 | 5.23 | TUUNAM3NEB5 | 5P | 3.15 | 0.591 | 1.181 | 1.713 | 0.26 | 0.191 | 0.312 | 3 | 005 | f | ||
| GH3 | 5.2 | 5.23 | TUUNAM3NEBA | 1.5P | 3.15 | 0.591 | 1.181 | 1.713 | 0.26 | 0.191 | 0.312 | 3 | 005 | f | CARBIDE | ||
| GH2 | 6.8 | 6.81 | TUU04N2NEB5 | 5P | 3.543 | 0.748 | 1.378 | 1.831 | 0.32 | 0.238 | 0.375 | 3 | 006 | f | |||
| STI 1/42UNC | GH2 | 6.8 | 6.81 | TUU04N2NEBA | 1.5P | 3.543 | 0.748 | 1.378 | 1.831 | 0.32 | 0.238 | 0.375 | 3 | 006 | f | ||
| -0 | GH3 | 6.8 | 6.81 | TUU04N3NEB5 | 5P | 3.543 | 0.748 | 1.378 | 1.831 | 0.32 | 0.238 | 0.375 | 3 | 006 | f | ||
| GH3 | 6.8 | 6.81 | TUU04N3NEBA | 1.5P | 3.543 | 0.748 | 1.378 | 1.831 | 0.32 | 0.238 | 0.375 | 3 | 006 | f | LONG | ||
| GH2 | 8.4 | 8.43 | TUU05O2NEB5 | 5P | 3.937 | 0.906 | 1.535 | 2.067 | 0.38 | 0.286 | 0.437 | 4 | 006 | f | |||
| GH2 | 8.4 | 8.43 | TUU05O2NEBA | 1.5P | 3.937 | 0.906 | 1.535 | 2.067 | 0.38 | 0.286 | 0.437 | 4 | 006 | f | |||
| STI 5/16-18UNC | GH3 | 8.4 | 8.43 | TUU05O3NEB5 | 5P | 3.937 | 0.906 | 1.535 | 2.067 | 0.38 | 0.286 | 0.437 | 4 | 006 | f | HAND | |
| GH3 | 8.4 | 8.43 | TUU05O3NEBA | 1.5P | 3.937 | 0.906 | 1.535 | 2.067 | 0.38 | 0.286 | 0.437 | 4 | 006 | f | TAPS | ||
| GH3 | 10 | 10.06 | TUU06P3NEB5 | 5P | 4.331 | 1.024 | - | 2.205 | 0.37 | 0.275 | 0.437 | 4 | 007 | f | |||
| GH3 | 10 | 10.06 | TUU06P3NEBA | 1.5P | 4.331 | 1.024 | - | 2.205 | 0.37 | 0.275 | 0.437 | 4 | 007 | f | |||
| STI 3/8-16UNC | GH4 | 10 | 10.06 | TUU06P4NEB5 | 5P | 4.331 | 1.024 | - | 2.205 | 0.37 | 0.275 | 0.437 | 4 | 007 | f | EG (STI) | |
| GH4 | 10 | 10.06 | TUU06P4NEBA | 1.5P | 4.331 | 1.024 | - | 2.205 | 0.37 | 0.275 | 0.437 | 4 | 007 | f | ANSI | ||
| GH3 | 11.7 | 11.71 | TUU07Q3NEB5 | 5P | 4.331 | 1.024 | - | 2.205 | 0.43 | 0.322 | 0.5 | 4 | 007 | f | |||
| GH3 | 11.7 | 11.71 | TUU07Q3NEBA | 1.5P | 4.331 | 1.024 | - | 2.205 | 0.43 | 0.322 | 0.5 | 4 | 007 | f | SPECIAL | ||
| STI 7/16-14UNC | GH4 | 11.7 | 11.71 | TUU07Q4NEB5 | 5P | 4.331 | 1.024 | - | 2.205 | 0.43 | 0.322 | 0.5 | 4 | 007 | f | THREADS, GAUGES | |
| GH4 | 11.7 | 11.71 | TUU07Q4NEBA | 1.5P | 4.331 | 1.024 | - | 2.205 | 0.43 | 0.322 | 0.5 | 4 | 007 | f | |||
| GH3 | 13.2 | 13.33 | TUU08R3NEB5 | 5P | 4.331 | 1.024 | - | 2.205 | 0.48 | 0.36 | 0.562 | 4 | 007 | f | |||
| GH3 | 13.2 | 13.33 | TUU08R3NEBA | 1.5P | 4.331 | 1.024 | - | 2.205 | 0.48 | 0.36 | 0.562 | 4 | 007 | f | THREAD | ||
| STI 1/2-13UNC | GH4 | 13.2 | 13.33 | TUU08R4NEB5 | 5P | 4.331 | 1.024 | - | 2.205 | 0.48 | 0.36 | 0.562 | 4 | 007 | f | MILLS | |
| GH4 | 13.2 | 13.33 | TUU08R4NEBA | 1.5P | 4.331 | 1.024 | - | 2.205 | 0.48 | 0.36 | 0.562 | 4 | 007 | f | |||
| EG(STI) UNF | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( inch ) | THL ( inch ) | LU ( inch ) | LS ( inch ) | DCON ( inch ) | K ( inch ) | LK ( inch ) | N | OF | Type | Stock | DIES |
| ANSI | |||||||||||||||||
| GH2 | 5.1 | 5.14 | TUUNAJ2NEB5 | 5P | 3.15 | 0.591 | 1.181 | 1.713 | 0.26 | 0.191 | 0.312 | 3 | 005 | f | |||
| STI No10-32UNF | GH2 | 5.1 | 5.14 | TUUNAJ2NEBA | 1.5P | 3.15 | 0.591 | 1.181 | 1.713 | 0.26 | 0.191 | 0.312 | 3 | 005 | f | CENTER | |
| . | GH3 | 5.1 | 5.14 | TUUNAJ3NEB5 | 5P | 3.15 | 0.591 | 1.181 | 1.713 | 0.26 | 0.191 | 0.312 | 3 | 005 | f | DRILLS | |
| GH3 | 5.1 | 5.14 | TUUNAJ3NEBA | 1.5P | 3.15 | 0.591 | 1.181 | 1.713 | 0.26 | 0.191 | 0.312 | 3 | 005 | f |
