Каталоги Yamawa твердосплавные метчики для закаленной стали
| M | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm | ) DCON ( mm ) | K ( mm ) | LK ( mm ) | N | OF | Type | Stock | Intro |
| JIS | |||||||||||||||||
| P3 | 1.1 | 1.13 | TCNR1.4C3A | 3P | 34 | 7 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | |||
| M1.4X0.3 | P3 | 1.1 | 1.13 | TCNR1.4C1A | 1.5P | 34 | 7 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | SP | |
| M16X035 | P3 | 1.25 | 1.3 | TCNR1.6D3A | 3P | 36 | 8 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | ||
| .. | P3 | 1.25 | 1.3 | TCNR1.6D1A | 1.5P | 36 | 8 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | ||
| M17X035 | P3 | 1.35 | 1.4 | TCNR1.7D3A | 3P | 36 | 8 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | ||
| .. | P3 | 1.35 | 1.4 | TCNR1.7D1A | 1.5P | 36 | 8 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | SL | |
| M2X04 | P3 | 1.6 | 1.65 | TCNR2.0E3A | 3P | 40 | 8 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | ||
| . | P3 | 1.6 | 1.65 | TCNR2.0E1A | 1.5P | 40 | 8 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | ||
| M22X045 | P3 | 1.75 | 1.81 | TCNR2.2F3A | 3P | 42 | 9.5 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | PO | |
| .. | P3 | 1.75 | 1.81 | TCNR2.2F1A | 1.5P | 42 | 9.5 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | ||
| P3 | 1.9 | 1.95 | TCNR2.3E3A | 3P | 42 | 8 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | |||
| M2.3X0.4 | P3 | 1.9 | 1.95 | TCNR2.3E1A | 1.5P | 42 | 8 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | ||
| P3 | 2.1 | 2.11 | TCNR2.5F3A | 3P | 44 | 9.5 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | ST | ||
| M2.5X0.45 | P3 | 2.1 | 2.11 | TCNR2.5F1A | 1.5P | 44 | 9.5 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | ||
| P3 | 2.2 | 2.21 | TCNR2.6F3A | 3P | 44 | 9.5 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | |||
| M2.6X0.45 | P3 | 2.2 | 2.21 | TCNR2.6F1A | 1.5P | 44 | 9.5 | - | - | 3 | 2.5 | 5 | 3 | 001 | f | ROLL | |
| M3X05 | P3 | 2.5 | 2.56 | TCNR3.0G3A | 3P | 46 | 11 | - | - | 4 | 3.2 | 6 | 3 | 001 | f | ||
| . | P3 | 2.5 | 2.56 | TCNR3.0G1A | 1.5P | 46 | 11 | - | - | 4 | 3.2 | 6 | 3 | 001 | f | ||
| M35X06 | P3 | 2.9 | 2.97 | TCNR3.5H3A | 3P | 48 | 11 | - | - | 4 | 3.2 | 6 | 3 | 001 | f | ||
| .. | P3 | 2.9 | 2.97 | TCNR3.5H1A | 1.5P | 48 | 11 | - | - | 4 | 3.2 | 6 | 3 | 001 | f | CARBIDE | |
| P3 | 3.3 | 3.38 | TCNR4.0I3A | 3P | 52 | 13 | - | - | 5 | 4 | 7 | 3 | 001 | f | |||
| M4X0.7 | P3 | 3.3 | 3.38 | TCNR4.0I1A | 1.5P | 52 | 13 | - | - | 5 | 4 | 7 | 3 | 001 | f | JIS | |
| M5X08 | P3 | 4.2 | 4.28 | TCNR5.0K3A | 3P | 60 | 16 | - | - | 5.5 | 4.5 | 7 | 3 | 001 | f | ||
| . | P3 | 4.2 | 4.28 | TCNR5.0K1A | 1.5P | 60 | 16 | - | - | 5.5 | 4.5 | 7 | 3 | 001 | f | LONG | |
| M6X1 | P3 | 5 | 5.09 | TCNR6.0M3A | 3P | 62 | 19 | - | - | 6 | 4.5 | 7 | 3 | 004 | f | ||
| P3 | 5 | 5.09 | TCNR6.0M1A | 1.5P | 62 | 19 | - | - | 6 | 4.5 | 7 | 3 | 004 | f | |||
| P3 | 6 | 6.09 | TCNR7.0M3A | 3P | 65 | 19 | - | - | 6.2 | 5 | 8 | 3 | 007 | f | HAND | ||
| M7X1 | P3 | 6 | 6.09 | TCNR7.0M1A | 1.5P | 65 | 19 | - | - | 6.2 | 5 | 8 | 3 | 007 | f | TAPS | |
| P3 | 6.8 | 6.85 | TCNR8.0N3A | 3P | 70 | 22 | - | - | 6.2 | 5 | 8 | 3 | 007 | f | |||
| P3 | 6.8 | 6.85 | TCNR8.0N1A | 1.5P | 70 | 22 | - | - | 6.2 | 5 | 8 | 3 | 007 | f | |||
| M8X1.25 | P4 | 6.8 | 6.85 | TCNS8.0N3A | 3P | 70 | 22 | - | - | 6.2 | 5 | 8 | 3 | 007 | f | EG (STI) | |
| P4 | 6.8 | 6.85 | TCNS8.0N1A | 1.5P | 70 | 22 | - | - | 6.2 | 5 | 8 | 3 | 007 | f | |||
| P3 | 8.5 | 8.6 | TCNR010O3A | 3P | 75 | 24 | - | - | 7 | 5.5 | 8 | 3 | 007 | f | |||
| M10X15 | P3 | 8.5 | 8.6 | TCNR010O1A | 1.5P | 75 | 24 | - | - | 7 | 5.5 | 8 | 3 | 007 | f | SPECIAL THREADS | |
| . | P4 | 8.5 | 8.6 | TCNS010O3A | 3P | 75 | 24 | - | - | 7 | 5.5 | 8 | 3 | 007 | f | , GAUGES | |
| P4 | 8.5 | 8.6 | TCNS010O1A | 1.5P | 75 | 24 | - | - | 7 | 5.5 | 8 | 3 | 007 | f | |||
| P3 | 10.3 | 10.36 | TCNR012P3A | 3P | 82 | 30 | - | - | 8.5 | 6.5 | 9 | 3 | 007 | f | |||
| M12X175 | P3 | 10.3 | 10.36 | TCNR012P1A | 1.5P | 82 | 30 | - | - | 8.5 | 6.5 | 9 | 3 | 007 | f | THREAD | |
| . | P4 | 10.3 | 10.36 | TCNS012P3A | 3P | 82 | 30 | - | - | 8.5 | 6.5 | 9 | 3 | 007 | f | MILLS | |
| P4 | 10.3 | 10.36 | TCNS012P1A | 1.5P | 82 | 30 | - | - | 8.5 | 6.5 | 9 | 3 | 007 | f | |||
| P3 | 12 | 12.12 | TCNR014Q3A | 3P | 88 | 30 | - | - | 10.5 | 8 | 11 | 4 | 007 | f | |||
| DIES | |||||||||||||||||
| P3 | 12 | 12.12 | TCNR014Q1A | 1.5P | 88 | 30 | - | - | 10.5 | 8 | 11 | 007 | f | ||||
| M14X2 | P4 | 12 | 12.12 | TCNS014Q3A | 3P | 88 | 30 | - | - | 10.5 | 8 | 11 | 4 | 007 | f | ||
| P4 | 12 | 12.12 | TCNS014Q1A | 1.5P | 88 | 30 | - | - | 10.5 | 8 | 11 | 4 | 007 | f | |||
| P4 | 14 | 14.12 | TCNS016Q3A | 3P | 95 | 30 | - | - | 12.5 | 10 | 13 | 4 | 007 | f | CENTER | ||
| M16X2 | P4 | 14 | 14.12 | TCNS016Q1A | 1.5P | 95 | 30 | - | - | 12.5 | 10 | 13 | 4 | 007 | f | DRILLS |
