TYPE: ROLL_019
DCON
THL LS LF
TYPE: ROLL_021
DCON THL LU LS LF
LK
LK
K
K
K
K
TYPE: ROLL_020 DCON
THL LS LF
Intro
K
LK K SP
SL
PO
ST
| M | TCTR (tolerance) | Bored Hol Max | e Ø(mm) Min | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF (Lobes) | Type | Stock | |
| JIS | ROLL | |||||||||||||||
| M1X0.25 | G4 | 0.92 | 0.89 | SRZM41.0B1 | 1P | 36 | 4.5 | - | 24 | 3 | 2.5 | 5 | 0(4) | 019 | ) | |
| M1.2X0.25 | G4 | 1.11 | 1.09 | SRZM41.2B1 | 1P | 36 | 4.5 | - | 24 | 3 | 2.5 | 5 | 0(4) | 019 | ) | JIS |
| M1.4X0.3 | G4 | 1.3 | 1.26 | SRZM41.4C1 | 1P | 36 | 5.4 | - | 24 | 3 | 2.5 | 5 | 0(4) | 019 | ) | |
| M1.6X0.35 | G4 | 1.46 | 1.43 | SRZM41.6D1 | 1P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 0(4) | 019 | ) | CARBIDE |
| M1.7X0.35 | G4 | 1.56 | 1.52 | SRZM41.7D1 | 1P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 0(4) | 019 | f | |
| M2X0.4 | G4 | 1.83 | 1.79 | SRZM42.0E1 | 1P | 42 | 7.2 | - | 27 | 3 | 2.5 | 5 | 0(4) | 020 | ) | |
| M2.5X0.45 | G5 | 2.32 | 2.27 | SRZM52.5F1 | 1P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 021 | ) | |
| M2.6X0.45 | G5 | 2.42 | 2.37 | SRZM52.6F1 | 1P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 021 | f | LONG |
| M3X0.5 | G5 | 2.8 | 2.75 | SRZM53.0G1 | 1P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 2(4) | 021 | ) | |
| M4X0.7 | G6 | 3.72 | 3.65 | SRZM64.0I1 | 1P | 52 | 11 | 17 | 29 | 5 | 4 | 7 | 2(4) | 021 | ) | |
| M5X0.8 | G6 | 4.67 | 4.59 | SRZM65.0K1 | 1P | 60 | 13 | 22 | 33 | 5.5 | 4.5 | 7 | 2(4) | 021 | ) | HAND |
| M6X1 | G6 | 5.58 | 5.47 | SRZM66.0M1 | 1P | 62 | 15 | 26 | 33 | 6 | 4.5 | 7 | 2(4) | 021 | ) | TAPS |
| MF | TCTR (tolerance) | Bored Hol Max | e Ø(mm) Min | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF (Lobes) | Type | Stock | |
| JIS | EG (STI) | |||||||||||||||
| M1.4X0.2 | G3 | 1.33 | 1.3 | SRZM31.4A1 | 1P | 36 | 3.6 | - | 24 | 3 | 2.5 | 5 | 0(4) | 019 | f | |
| M1.6X0.2 | G3 | 1.53 | 1.5 | SRZM31.6A1 | 1P | 36 | 3.6 | - | 24 | 3 | 2.5 | 5 | 0(4) | 019 | f | |
| UNC | TCTR (tolerance) | Bored Hol Max | e Ø(mm) Min | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF (Lobes) | Type | Stock | SPECIAL THREADS, GAUGES |
| JIS | ||||||||||||||||
| No.2-56UNC | G4 | 2.01 | 1.96 | SRZM4UN2E1 | 1P | 42 | 8.1 | - | 27 | 3 | 2.5 | 5 | 0(3) | 020 | f | |
| No.4-40UNC | G5 | 2.61 | 2.54 | SRZM5UN4H1 | 1P | 46 | 9 | 14 | 25 | 4 | 3.2 | 6 | 0(4) | 021 | f | THREAD MILLS |
