Каталоги Yamawa твердосплавные метчики для закаленной стали
| Intro | M | TCTR (tolerance) | Bored Ho Max | le Ø(mm) Min | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm | ) NOF (Lobes) | Type | Stock |
| JIS | ||||||||||||||||
| G5 | 2.42 | 2.37 | NRZP52.6FP | 4P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | ||
| SP | M26X04 | G5 | 2.42 | 2.37 | NRZP52.6FB | 2P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f |
| ..5 | G6(G5+13) | 2.44 | 2.39 | NRZP62.6FP | 4P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | |
| G6(G5+13) | 2.44 | 2.39 | NRZP62.6FB | 2P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 0(4) | 012 | f | ||
| G5 | 2.8 | 2.75 | NRZP53.0GP | 4P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 4(4) | 012 | f | ||
| SL | G5 | 2.8 | 2.75 | NRZP53.0GB | 2P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 4(4) | 012 | f | |
| G6(G5+13) | 2.82 | 2.76 | NRZP63.0GP | 4P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 4(4) | 012 | f | ||
| M3X05 | G6(G5+13) | 2.82 | 2.76 | NRZP63.0GB | 2P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 4(4) | 012 | f | |
| PO | . | G7(G5+26) | 2.83 | 2.77 | NRZP73.0GP | 4P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 4(4) | 012 | f |
| G7(G5+26) | 2.83 | 2.77 | NRZP73.0GB | 2P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 4(4) | 012 | f | ||
| G8(G5+39) | 2.84 | 2.79 | NRZP83.0GP | 4P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 4(4) | 012 | f | ||
| G8(G5+39) | 2.84 | 2.79 | NRZP83.0GB | 2P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 4(4) | 012 | f | ||
| ST | G5 | 3.25 | 3.19 | NRZP53.5HP | 4P | 52 | 11 | 16 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | |
| G5 | 3.25 | 3.19 | NRZP53.5HB | 2P | 52 | 11 | 16 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | ||
| M35X06 | G6(G5+13) | 3.26 | 3.2 | NRZP63.5HP | 4P | 52 | 11 | 16 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | |
| .. | G6(G5+13) | 3.26 | 3.2 | NRZP63.5HB | 2P | 52 | 11 | 16 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | |
| ROLL | G7(G5+26) | 3.28 | 3.21 | NRZP73.5HP | 4P | 52 | 11 | 16 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | |
| JIS | G7(G5+26) | 3.28 | 3.21 | NRZP73.5HB | 2P | 52 | 11 | 16 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | |
| G5 | 3.71 | 3.65 | NRZP54.0IP | 4P | 52 | 11 | 17 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | ||
| CARBIDE | G5 | 3.71 | 3.65 | NRZP54.0IB | 2P | 52 | 11 | 17 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | |
| G6 | 3.72 | 3.65 | NRZP64.0IP | 4P | 52 | 11 | 17 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | ||
| M4X07 | G6 | 3.72 | 3.65 | NRZP64.0IB | 2P | 52 | 11 | 17 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | |
| . | G7(G6+13) | 3.74 | 3.66 | NRZP74.0IP | 4P | 52 | 11 | 17 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | |
| LONG | G7(G6+13) | 3.74 | 3.66 | NRZP74.0IB | 2P | 52 | 11 | 17 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | |
| G8(G6+26) | 3.75 | 3.67 | NRZP84.0IP | 4P | 52 | 11 | 17 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | ||
| G8(G6+26) | 3.75 | 3.67 | NRZP84.0IB | 2P | 52 | 11 | 17 | 29 | 5 | 4 | 7 | 4(4) | 012 | f | ||
| HAND | G5 | 4.66 | 4.57 | NRZP55.0KP | 4P | 60 | 13 | 22 | 33 | 5.5 | 4.5 | 7 | 4(4) | 012 | f | |
| TAPS | G5 | 4.66 | 4.57 | NRZP55.0KB | 2P | 60 | 13 | 22 | 33 | 5.5 | 4.5 | 7 | 4(4) | 012 | f | |
| G6 | 4.67 | 4.59 | NRZP65.0KP | 4P | 60 | 13 | 22 | 33 | 5.5 | 4.5 | 7 | 4(4) | 012 | f | ||
| G6 | 4.67 | 4.59 | NRZP65.0KB | 2P | 60 | 13 | 22 | 33 | 5.5 | 4.5 | 7 | 4(4) | 012 | f | ||
| EG (STI) | M5X0.8 | G7(G6+13) | 4.68 | 4.6 | NRZP75.0KP | 4P | 60 | 13 | 22 | 33 | 5.5 | 4.5 | 7 | 4(4) | 012 | f |
| G7(G6+13) | 4.68 | 4.6 | NRZP75.0KB | 2P | 60 | 13 | 22 | 33 | 5.5 | 4.5 | 7 | 4(4) | 012 | f | ||
| G8(G6+26) | 4.7 | 4.61 | NRZP85.0KP | 4P | 60 | 13 | 22 | 33 | 5.5 | 4.5 | 7 | 4(4) | 012 | f | ||
| SPECIAL THREADS | G8(G6+26) | 4.7 | 4.61 | NRZP85.0KB | 2P | 60 | 13 | 22 | 33 | 5.5 | 4.5 | 7 | 4(4) | 012 | f | |
| , GAUGES | G5 | 5.57 | 5.46 | NRZP56.0MP | 4P | 62 | 15 | 26 | 33 | 6 | 4.5 | 7 | 4(4) | 012 | f | |
| G5 | 5.57 | 5.46 | NRZP56.0MB | 2P | 62 | 15 | 26 | 33 | 6 | 4.5 | 7 | 4(4) | 012 | f | ||
| G6 | 5.58 | 5.47 | NRZP66.0MP | 4P | 62 | 15 | 26 | 33 | 6 | 4.5 | 7 | 4(4) | 012 | f | ||
| THREAD | M6X1 | G6 | 5.58 | 5.47 | NRZP66.0MB | 2P | 62 | 15 | 26 | 33 | 6 | 4.5 | 7 | 4(4) | 012 | f |
| MILLS | G7(G6+13) | 5.59 | 5.49 | NRZP76.0MP | 4P | 62 | 15 | 26 | 33 | 6 | 4.5 | 7 | 4(4) | 012 | f | |
| G7(G6+13) | 5.59 | 5.49 | NRZP76.0MB | 2P | 62 | 15 | 26 | 33 | 6 | 4.5 | 7 | 4(4) | 012 | f | ||
| G7 | 6.59 | 6.48 | NRZM77.0MP | 4P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 4(4) | 026 | f | ||
| DIES | M7X1 | G7 | 6.59 | 6.48 | NRZM77.0MB | 2P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 4(4) | 026 | f |
| G7 | 7.49 | 7.37 | NRZM78.0NP | 4P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 3(6) | 026 | f | ||
| MX | G7 | 7.49 | 7.37 | NRZM78.0NB | 2P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 3(6) | 026 | f | |
| CENTER | 81.25 | G8(G7+13) | 7.51 | 7.37 | NRZM88.0NP | 4P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 3(6) | 026 | f |
| DRILLS | G8(G7+13) | 7.51 | 7.37 | NRZM88.0NB | 2P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 3(6) | 026 | f |
