Straight Fluted Taps Intro M TCTR Ø Hole Ø(tolerance)(mm)(mm)CodeTHCHT(chamfer)LF(mm)THL(mm) LU(mm) LS DCON K(mm)(mm)(mm)LK(mm)NOFTypeStock JIS P2 6 6.09 TNMQ7.0M5-L 5P 70 19 - 36 6.2 5 8 4 002 f M7X1 SP P2 6 6.09 TNMQ7.0M1-L 1.5P 70 19 - 36 6.2 5 8 4 002 f P3 6.8 6.85 TNMR8.0N5-L 5P 70 19 - 36 6.2 5 8 4 002 f P3 6.8 6.85 TNMR8.0N1-L 1.5P 70 19 - 36 6.2 5 8 4 002 ) M8X1.25 P3 6.8 6.85 TNMR8.0N5TL 5P 70 19 - 36 6.2 5 8 3 002 f SL P3 6.8 6.85 TNMR8.0N1TL 1.5P 70 19 - 36 6.2 5 8 3 002 f P3 7.8 7.85 TNMR9.0N5-L 5P 75 23 - 38 7 5.5 8 4 002 f M9X1.25 P3 7.8 7.85 TNMR9.0N1-L 1.5P 75 23 - 38 7 5.5 8 4 002 f PO M10X1.5 P3 8.5 8.6 TNMR010O5-L 5P 75 23 - 38 7 5.5 8 4 002 f P3 8.5 8.6 TNMR010O1-L 1.5P 75 23 - 38 7 5.5 8 4 002 ) P4 9.5 9.6 TNMS011O5-L 5P 82 26 - 42 8.5 6.5 9 4 002 f M11X1.5 P4 9.5 9.6 TNMS011O1-L 1.5P 82 26 - 42 8.5 6.5 9 4 002 f ST P3 10.3 10.36 TNMR012P5-L 5P 82 26 - 42 8.5 6.5 9 4 002 f M12X1.75 JIS P3 10.3 10.36 TNMR012P1-L 1.5P 82 26 - 42 8.5 6.5 9 4 002 ) P3 12 12.12 TNMR014Q5-L 5P 88 26 - 45 10.5 8 11 4 002 f M14X2 P3 12 12.12 TNMR014Q1-L 1.5P 88 26 - 45 10.5 8 11 4 002 ) ROLL P3 14 14.12 TNMR016Q5-L 5P 95 26 - 48 12.5 10 13 4 002 f M16X2 P3 14 14.12 TNMR016Q1-L 1.5P 95 26 - 48 12.5 10 13 4 002 ) P4 15.5 15.63 TNMS018R5-L 5P 100 33 - 51 14 11 14 4 002 f M18X2.5 CARBIDE P4 15.5 15.63 TNMS018R1-L 1.5P 100 33 - 51 14 11 14 4 002 ) P4 17.5 17.63 TNMS020R5-L 5P 105 33 - 50 15 12 15 4 002 f M20X2.5 P4 17.5 17.63 TNMS020R1-L 1.5P 105 33 - 50 15 12 15 4 002 ) P4 19.5 19.63 TNMS022R5-L 5P 115 33 - 55 17 13 16 4 002 f LONG M22X2.5 P4 19.5 19.63 TNMS022R1-L 1.5P 115 33 - 55 17 13 16 4 002 ) P4 21 21.13 TNMS024S5-L 5P 120 39 - 55 19 15 18 4 002 f M24X3 P4 21 21.13 TNMS024S1-L 1.5P 120 39 - 55 19 15 18 4 002 ) HAND P4 24 24.13 TNMS027S5-L 5P 130 39 - 60 20 15 18 4 002 f TAPS M27X3 P4 24 24.13 TNMS027S1-L 1.5P 130 39 - 60 20 15 18 4 002 f P4 26.5 26.63 TNMS030T5-L 5P 135 46 - 62 23 17 20 4 002 f M30X3.5 P4 26.5 26.63 TNMS030T1-L 1.5P 135 46 - 62 23 17 20 4 002 f EG (STI) P4 29.5 29.63 TNMS033T5-L 5P 145 46 - 67 25 19 22 4 002 f M33X3.5 P4 29.5 29.63 TNMS033T1-L 1.5P 145 46 - 67 25 19 22 4 002 f P5 32 32.12 TNMT036U5-L 5P 155 52 - 71 28 21 24 4 002 f SPECIAL M36X4 P5 32 32.12 TNMT036U1-L 1.5P 155 52 - 71 28 21 24 4 002 f THREADS,GAUGESM39X4 P5 35 35.12 TNMT039U5-L 5P 165 52 - 76 30 23 26 4 002 f P5 35 35.12 TNMT039U1-L 1.5P 165 52 - 76 30 23 26 4 002 f P5 37.5 37.63 TNMT042V5-L 5P 175 59 - 81 32 26 30 4 002 f THREAD M42X4.5 P5 37.5 37.63 TNMT042V1-L 1.5P 175 59 - 81 32 26 30 4 002 f MILLS P5 40.5 40.63 TNMT045V5-L 5P 180 59 - 83 35 26 30 4 002 f M45X4.5 P5 40.5 40.63 TNMT045V1-L 1.5P 180 59 - 83 35 26 30 4 002 f P5 43 43.12 TNMT048W5-L 5P 185 65 - 85 38 29 32 4 002 f DIES M48X5 P5 43 43.12 TNMT048W1-L 1.5P 185 65 - 85 38 29 32 4 002 f MF TCTR Ø Hole Ø(tolerance)(mm)(mm)CodeTHCHT(chamfer)LF(mm)THL(mm) LU(mm) LS DCON K(mm)(mm)(mm)LK(mm)NOFTypeStock CENTER JIS DRILLS M3X0.35 P2 2.7 2.7 TNMQ3.0D5-L 5P 46 6.5 14 26 4 3.2 6 3 001 f P2 2.7 2.7 TNMQ3.0D1-L 1.5P 46 6.5 14 26 4 3.2 6 3 001 f Technical info 322
