| M | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | N | OF | Type | Stock | Intro |
| JIS | |||||||||||||||||
| P1 | 0.75 | 0.77 | TNMP1.0B5 | 5P | 36 | 4.5 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | f | |||
| M1X0.25 | P1 | 0.75 | 0.77 | TNMP1.0B1 | 1.5P | 36 | 4.5 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | ) | SP | |
| M11X025 | P1 | 0.85 | 0.87 | TNMP1.1B5 | 5P | 36 | 4.5 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | f | ||
| .. | P1 | 0.85 | 0.87 | TNMP1.1B1 | 1.5P | 36 | 4.5 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | ) | ||
| P1 | 0.95 | 0.97 | TNMP1.2B5 | 5P | 36 | 4.5 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | f | |||
| P1 | 0.95 | 0.97 | TNMP1.2B1 | 1.5P | 36 | 4.5 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | ) | SL | ||
| M1.2X0.25 | P3(P1+30) | 0.95 | 0.97 | TNMR1.2B5 | 5P | 36 | 4.5 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | f | ||
| P3(P1+30) | 0.95 | 0.97 | TNMR1.2B1 | 1.5P | 36 | 4.5 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | f | |||
| P1 | 1.1 | 1.13 | TNMP1.4C5 | 5P | 36 | 5.4 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | ) | PO | ||
| P1 | 1.1 | 1.13 | TNMP1.4C1 | 1.5P | 36 | 5.4 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | f | |||
| M1.4X0.3 | P3(P1+30) | 1.1 | 1.13 | TNMR1.4C5 | 5P | 36 | 5.4 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | f | ||
| P3(P1+30) | 1.1 | 1.13 | TNMR1.4C1 | 1.5P | 36 | 5.4 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | f | |||
| P2 | 1.25 | 1.3 | TNMQ1.6D5 | 5P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | f | ST | ||
| M1.6X0.35 | P2 | 1.25 | 1.3 | TNMQ1.6D1 | 1.5P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | ) | JIS | |
| P1 | 1.35 | 1.4 | TNMP1.7D5 | 5P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | f | |||
| M17X035 | P1 | 1.35 | 1.4 | TNMP1.7D1 | 1.5P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | ) | ||
| .. | P3(P1+30) | 1.35 | 1.4 | TNMR1.7D5 | 5P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | f | ROLL | |
| P3(P1+30) | 1.35 | 1.4 | TNMR1.7D1 | 1.5P | 36 | 6.3 | - | 24 | 3 | 2.5 | 5 | 3 | 005 | f | |||
| M18X035 | P2 | 1.45 | 1.5 | TNMQ1.8D5 | 5P | 42 | 6.3 | - | 27 | 3 | 2.5 | 5 | 3 | 005 | f | ||
| .. | P2 | 1.45 | 1.5 | TNMQ1.8D1 | 1.5P | 42 | 6.3 | - | 27 | 3 | 2.5 | 5 | 3 | 005 | ) | CARBIDE | |
| P1 | 1.6 | 1.65 | TNMP2.0E5 | 5P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | f | |||
| P1 | 1.6 | 1.65 | TNMP2.0E1 | 1.5P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | ) | |||
| M2X04 | P3(P1+30) | 1.6 | 1.65 | TNMR2.0E5 | 5P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | f | ||
| . | P3(P1+30) | 1.6 | 1.65 | TNMR2.0E1 | 1.5P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | f | LONG | |
| P4(P1+45) | 1.6 | 1.65 | TNMS2.0E5 | 5P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | f | |||
| P4(P1+45) | 1.6 | 1.65 | TNMS2.0E1 | 1.5P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | f | |||
| M22X045 | P2 | 1.75 | 1.81 | TNMQ2.2F5 | 5P | 42 | 8.1 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | f | HAND | |
| .. | P2 | 1.75 | 1.81 | TNMQ2.2F1 | 1.5P | 42 | 8.1 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | ) | TAPS | |
| P1 | 1.9 | 1.95 | TNMP2.3E5 | 5P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | f | |||
| P1 | 1.9 | 1.95 | TNMP2.3E1 | 1.5P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | ) | |||
| M23X04 | P3(P1+30) | 1.9 | 1.95 | TNMR2.3E5 | 5P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | f | EG (STI) | |
| .. | P3(P1+30) | 1.9 | 1.95 | TNMR2.3E1 | 1.5P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | f | ||
| P4(P1+45) | 1.9 | 1.95 | TNMS2.3E5 | 5P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | f | |||
| P4(P1+45) | 1.9 | 1.95 | TNMS2.3E1 | 1.5P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | f | SPECIAL | ||
| P2 | 2.1 | 2.11 | TNMQ2.5F5 | 5P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | f | THREADS, GAUGES | ||
| P2 | 2.1 | 2.11 | TNMQ2.5F1 | 1.5P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | ) | |||
| M25X045 | P3(P2+15) | 2.1 | 2.11 | TNMR2.5F5 | 5P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | f | ||
| .. | P3(P2+15) | 2.1 | 2.11 | TNMR2.5F1 | 1.5P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | f | THREAD | |
| P4(P2+30) | 2.1 | 2.11 | TNMS2.5F5 | 5P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | f | MILLS | ||
| P4(P2+30) | 2.1 | 2.11 | TNMS2.5F1 | 1.5P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | f | |||
| P1 | 2.2 | 2.21 | TNMP2.6F5 | 5P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | f | |||
| P1 | 2.2 | 2.21 | TNMP2.6F1 | 1.5P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | ) | DIES | ||
| P3(P1+30) | 2.2 | 2.21 | TNMR2.6F5 | 5P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | f | |||
| M2.6X0.45 | P3(P1+30) | 2.2 | 2.21 | TNMR2.6F1 | 1.5P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | f | ||
| P4(P1+45) | 2.2 | 2.21 | TNMS2.6F5 | 5P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | f | CENTER | ||
| P4(P1+45) | 2.2 | 2.21 | TNMS2.6F1 | 1.5P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | f | DRILLS | ||
| P2 | 2.45 | 2.47 | TNMQ3.0H5 | 5P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 3 | 001 | f | |||
| 3M0.6 | P2 | 2.45 | 2.47 | TNMQ3.0H1 | 1.5P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 3 | 001 | f |
