| Intro | UNC | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( inch ) ( | LT inch | ) THL ( inch ) | LU ( inch ) LS ( inch ) | DCON ( inch ) K ( inch ) LK ( inch ) | NOF | Type | Stock |
| ANSI | ||||||||||||||
| GH3 | 10.9 | 10.91 | Y87521 | 3P | 3.375 | - | 0.630 | - - | 0.37 0.275 0.437 | 3 | 014 | f | ||
| SP | GH3 | 10.9 | 10.91 | Y87500 | 1.5P | 3.375 | - | 0.630 | - - | 0.37 0.275 0.437 | 3 | 014 | f | |
| ANSI | 1/2-13UNC | GH5 | 10.9 | 10.91 | Y87551 | 3P | 3.375 | - | 0.630 | - - | 0.37 0.275 0.437 | 3 | 014 | f |
| GH5 | 10.9 | 10.91 | Y87051 | 1.5P | 3.375 | - | 0.630 | - - | 0.37 0.275 0.437 | 3 | 014 | f | ||
| GH7 | 10.9 | 10.91 | Y87581 | 3P | 3.375 | - | 0.630 | - - | 0.37 0.275 0.437 | 3 | 014 | f | ||
| SL | GH3 | 13.6 | 13.75 | Y87525 | 3P | 3.812 | - | 0.748 | - - | 0.48 0.36 0.562 | 4 | 014 | f | |
| 5/811UNC | GH5 | 13.6 | 13.75 | Y87555 | 3P | 3.812 | - | 0.748 | - - | 0.48 0.36 0.562 | 4 | 014 | f | |
| - | GH7 | 13.6 | 13.75 | Y87585 | 3P | 3.812 | - | 0.748 | - - | 0.48 0.36 0.562 | 4 | 014 | f | |
| PO | GH3 | 13.6 | 13.75 | Y87025 | 3P | 3.812 | - | 0.748 | - - | 0.48 0.36 0.562 | 4 | 014 | f | |
| GH3 | 16.6 | 16.7 | Y87527 | 3P | 4.25 | - | 0.827 | - - | 0.59 0.442 0.687 | 4 | 014 | f | ||
| 3/4-10UNC | GH3 | 16.6 | 16.7 | Y87027 | 1.5P | 4.25 | - | 0.827 | - - | 0.59 0.442 0.687 | 4 | 014 | f | |
| GH5 | 16.6 | 16.7 | Y87557 | 3P | 4.25 | - | 0.827 | - - | 0.59 0.442 0.687 | 4 | 014 | f | ||
| ST | UNF | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( inch ) ( | LT inch | ) THL ( inch ) | LU ( inch ) LS ( inch ) | DCON ( inch ) K ( inch ) LK ( inch ) | NOF | Type | Stock |
| ANSI | ||||||||||||||
| GH2 | 4.1 | 4.12 | Y87511 | 3P | 2.375 | - | 0.276 | 0.875 - | 0.19 0.152 0.25 | 3 | 002 | f | ||
| ROLL | GH3 | 4.1 | 4.12 | Y87510 | 3P | 2.375 | - | 0.276 | 0.875 - | 0.19 0.152 0.25 | 3 | 002 | ) | |
| GH3 | 4.1 | 4.12 | Y81556 | 1.5P | 2.375 | - | 0.276 | 0.875 - | 0.19 0.152 0.25 | 3 | 002 | f | ||
| GH4 | 4.1 | 4.12 | Y87530 | 3P | 2.375 | - | 0.276 | 0.875 - | 0.19 0.152 0.25 | 3 | 002 | f | ||
| CARBIDE | No.10-32UNF | GH5 | 4.1 | 4.12 | Y87540 | 3P | 2.375 | - | 0.276 | 0.875 - | 0.19 0.152 0.25 | 3 | 002 | f |
| GH5 | 4.1 | 4.12 | Y87040 | 1.5P | 2.375 | - | 0.276 | 0.875 - | 0.19 0.152 0.25 | 3 | 002 | f | ||
| GH6 | 4.1 | 4.12 | Y87561 | 3P | 2.375 | - | 0.276 | 0.875 - | 0.19 0.152 0.25 | 3 | 002 | f | ||
| GH7 | 4.1 | 4.12 | Y87570 | 3P | 2.375 | - | 0.276 | 0.875 - | 0.19 0.152 0.25 | 3 | 002 | f | ||
| LONG | GH3 | 5.5 | 5.53 | Y87514 | 3P | 2.5 | - | 0.354 | 1 - | 0.26 0.191 0.312 | 3 | 002 | ) | |
| GH3 | 5.5 | 5.53 | Y87579 | 1.5P | 2.5 | - | 0.354 | 1 - | 0.26 0.191 0.312 | 3 | 002 | f | ||
| GH4 | 5.5 | 5.53 | Y87531 | 3P | 2.5 | - | 0.354 | 1 - | 0.26 0.191 0.312 | 3 | 002 | f | ||
| HAND | 1/42NF | GH4 | 5.5 | 5.53 | Y87031 | 1.5P | 2.5 | - | 0.354 | 1 - | 0.26 0.191 0.312 | 3 | 002 | f |
| TAPS | -8U | GH5 | 5.5 | 5.53 | Y87544 | 3P | 2.5 | - | 0.354 | 1 - | 0.26 0.191 0.312 | 3 | 002 | f |
| GH5 | 5.5 | 5.53 | Y87443 | 1.5P | 2.5 | - | 0.354 | 1 - | 0.26 0.191 0.312 | 3 | 002 | f | ||
| GH6 | 5.5 | 5.53 | Y87562 | 3P | 2.5 | - | 0.354 | 1 - | 0.26 0.191 0.312 | 3 | 002 | f | ||
| EG (STI) | GH7 | 5.5 | 5.53 | Y87574 | 3P | 2.5 | - | 0.354 | 1 - | 0.26 0.191 0.312 | 3 | 002 | f | |
| GH3 | 6.9 | 6.97 | Y87516 | 3P | 2.718 | - | 0.394 | 1.125 - | 0.32 0.238 0.375 | 3 | 002 | ) | ||
| GH3 | 6.9 | 6.97 | Y87577 | 1.5P | 2.718 | - | 0.394 | 1.125 - | 0.32 0.238 0.375 | 3 | 002 | f | ||
| SPECIAL | GH4 | 6.9 | 6.97 | Y87532 | 3P | 2.718 | - | 0.394 | 1.125 - | 0.32 0.238 0.375 | 3 | 002 | f | |
| THREADS, GAUGES | 5/16-24UNF | GH5 | 6.9 | 6.97 | Y87546 | 3P | 2.718 | - | 0.394 | 1.125 - | 0.32 0.238 0.375 | 3 | 002 | f |
| GH6 | 6.9 | 6.97 | Y87563 | 3P | 2.718 | - | 0.394 | 1.125 - | 0.32 0.238 0.375 | 3 | 002 | f | ||
| GH7 | 6.9 | 6.97 | Y87576 | 3P | 2.718 | - | 0.394 | 1.125 - | 0.32 0.238 0.375 | 3 | 002 | f | ||
| THREAD | GH4 | 6.9 | 6.97 | Y87032 | 3P | 2.718 | - | 0.394 | 1.125 - | 0.32 0.238 0.375 | 3 | 002 | f | |
| MILLS | GH3 | 8.5 | 8.57 | Y87518 | 3P | 2.937 | - | 0.394 | 1.25 - | 0.38 0.286 0.437 | 3 | 002 | ) | |
| GH4 | 8.5 | 8.57 | Y87533 | 3P | 2.937 | - | 0.394 | 1.25 - | 0.38 0.286 0.437 | 3 | 002 | f | ||
| GH4 | 8.5 | 8.57 | Y87033 | 1.5P | 2.937 | - | 0.394 | 1.25 - | 0.38 0.286 0.437 | 3 | 002 | f | ||
| DIES | 3/8-24UNF | GH5 | 8.5 | 8.57 | Y87548 | 3P | 2.937 | - | 0.394 | 1.25 - | 0.38 0.286 0.437 | 3 | 002 | f |
| GH6 | 8.5 | 8.57 | Y87564 | 3P | 2.937 | - | 0.394 | 1.25 - | 0.38 0.286 0.437 | 3 | 002 | f | ||
| GH7 | 8.5 | 8.57 | Y87578 | 3P | 2.937 | - | 0.394 | 1.25 - | 0.38 0.286 0.437 | 3 | 002 | f | ||
| CENTER | GH3 | 8.5 | 8.57 | Y87575 | 3P | 2.937 | - | 0.394 | 1.25 - | 0.38 0.286 0.437 | 3 | 002 | f | |
| DRILLS |
