| Intro | MF | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | LT mm | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF | Type | Stock |
| JIS | |||||||||||||||||
| M16X1 | P2 | 15 | 15.09 | SPQ016M | 2.5P | 95 | - | 26 | - | 48 | 12.5 | 10 | 13 | 3 | 013 | f | |
| SP | M17X1.5 | P2 | 15.5 | 15.6 | SPQ017O | 2.5P | 100 | - | 33 | - | 51 | 14 | 11 | 14 | 4 | 013 | ) |
| M17X1 | P2 | 16 | 16.09 | SPQ017M | 2.5P | 100 | - | 18 | - | 51 | 14 | 11 | 14 | 4 | 020 | ) | |
| JIS | M18X2 | P3 | 16 | 16.12 | SPR018Q | 2.5P | 100 | - | 33 | - | 51 | 14 | 11 | 14 | 4 | 013 | f |
| P2 | 16.5 | 16.6 | SPQ018O | 2.5P | 100 | - | 33 | - | 51 | 14 | 11 | 14 | 4 | 013 | f | ||
| SL | M18X1.5 | P3(P2+20) | 16.5 | 16.6 | SPR018O | 2.5P | 100 | - | 33 | - | 51 | 14 | 11 | 14 | 4 | 013 | f |
| P4(P2+40) | 16.5 | 16.6 | SPS018O | 2.5P | 100 | - | 33 | - | 51 | 14 | 11 | 14 | 4 | 013 | f | ||
| M18X1.25 | P2 | 16.8 | 16.85 | SPQ018N | 2.5P | 100 | - | 33 | - | 51 | 14 | 11 | 14 | 4 | 013 | f | |
| PO | M18X1 | P2 | 17 | 17.09 | SPQ018M | 2.5P | 100 | - | 18 | - | 51 | 14 | 11 | 14 | 4 | 020 | f |
| M19X1.5 | P3 | 17.5 | 17.6 | SPR019O | 2.5P | 105 | - | 33 | - | 50 | 15 | 12 | 15 | 4 | 013 | f | |
| M19X1 | P2 | 18 | 18.09 | SPQ019M | 2.5P | 105 | - | 18 | - | 50 | 15 | 12 | 15 | 4 | 020 | ) | |
| M20X2 | P3 | 18 | 18.12 | SPR020Q | 2.5P | 105 | - | 33 | - | 50 | 15 | 12 | 15 | 4 | 013 | f | |
| ST | P3 | 18.5 | 18.6 | SPR020O | 2.5P | 105 | - | 33 | - | 50 | 15 | 12 | 15 | 4 | 013 | f | |
| M20X1.5 | P4(P3+20) | 18.5 | 18.6 | SPS020O | 2.5P | 105 | - | 33 | - | 50 | 15 | 12 | 15 | 4 | 013 | f | |
| P5(P3+40) | 18.5 | 18.6 | SPT020O | 2.5P | 105 | - | 33 | - | 50 | 15 | 12 | 15 | 4 | 013 | f | ||
| M20X1.25 | P2 | 18.8 | 18.85 | SPQ020N | 2.5P | 105 | - | 18 | - | 50 | 15 | 12 | 15 | 4 | 020 | f | |
| ROLL | M20X1 | P2 | 19 | 19.09 | SPQ020M | 2.5P | 105 | - | 18 | - | 50 | 15 | 12 | 15 | 4 | 020 | f |
| M22X2 | P3 | 20 | 20.12 | SPR022Q | 2.5P | 115 | - | 33 | - | 55 | 17 | 13 | 16 | 4 | 013 | f | |
| P3 | 20.5 | 20.6 | SPR022O | 2.5P | 115 | - | 33 | - | 55 | 17 | 13 | 16 | 4 | 013 | f | ||
| CARBIDE | M22X1.5 | P4(P3+20) | 20.5 | 20.6 | SPS022O | 2.5P | 115 | - | 33 | - | 55 | 17 | 13 | 16 | 4 | 013 | f |
| P5(P3+40) | 20.5 | 20.6 | SPT022O | 2.5P | 115 | - | 33 | - | 55 | 17 | 13 | 16 | 4 | 013 | f | ||
| M22X1 | P2 | 21 | 21.09 | SPQ022M | 2.5P | 115 | - | 19 | - | 55 | 17 | 13 | 16 | 4 | 020 | f | |
| M23X1.5 | P3 | 21.5 | 21.6 | SPR023O | 2.5P | 120 | - | 39 | - | 55 | 19 | 15 | 18 | 4 | 013 | f | |
| LONG | M24X2 | P3 | 22 | 22.12 | SPR024Q | 2.5P | 120 | - | 39 | - | 55 | 19 | 15 | 18 | 4 | 013 | f |
| P3 | 22.5 | 22.6 | SPR024O | 2.5P | 120 | - | 39 | - | 55 | 19 | 15 | 18 | 4 | 013 | f | ||
| M24X1.5 | P4(P3+20) | 22.5 | 22.6 | SPS024O | 2.5P | 120 | - | 39 | - | 55 | 19 | 15 | 18 | 4 | 013 | f | |
| HAND | M24X1 | P2 | 23 | 23.09 | SPQ024M | 2.5P | 120 | - | 19 | - | 55 | 19 | 15 | 18 | 4 | 020 | f |
| TAPS | M25X2 | P3 | 23 | 23.12 | SPR025Q | 2.5P | 125 | - | 39 | - | 58 | 19 | 15 | 18 | 4 | 013 | f |
| M25X1.5 | P3 | 23.5 | 23.6 | SPR025O | 2.5P | 125 | - | 39 | - | 58 | 19 | 15 | 18 | 4 | 013 | f | |
| M25X1 | P2 | 24 | 24.09 | SPQ025M | 2.5P | 125 | - | 20 | - | 58 | 19 | 15 | 18 | 4 | 020 | f | |
| EG (STI) | M26X3 | P3 | 23 | 23.12 | SPR026S | 2.5P | 130 | - | 39 | - | 60 | 20 | 15 | 18 | 4 | 013 | f |
| M26X2 | P3 | 24 | 24.12 | SPR026Q | 2.5P | 130 | - | 39 | - | 60 | 20 | 15 | 18 | 4 | 013 | f | |
| M26X1.5 | P3 | 24.5 | 24.6 | SPR026O | 2.5P | 130 | - | 39 | - | 60 | 20 | 15 | 18 | 4 | 013 | f | |
| SPECIAL | M26X1 | P2 | 25 | 25.09 | SPQ026M | 2.5P | 130 | - | 20 | - | 60 | 20 | 15 | 18 | 4 | 020 | f |
| THREADS, GAUGES | M27X2 | P3 | 25 | 25.12 | SPR027Q | 2.5P | 130 | - | 39 | - | 60 | 20 | 15 | 18 | 4 | 013 | f |
| M27X1.5 | P3 | 25.5 | 25.6 | SPR027O | 2.5P | 130 | - | 39 | - | 60 | 20 | 15 | 18 | 4 | 013 | f | |
| M27X1 | P2 | 26 | 26.09 | SPQ027M | 2.5P | 130 | - | 20 | - | 60 | 20 | 15 | 18 | 4 | 020 | f | |
| THREAD | M28X2 | P3 | 26 | 26.12 | SPR028Q | 2.5P | 135 | - | 46 | - | 62 | 23 | 17 | 20 | 4 | 013 | f |
| MILLS | M28X1.5 | P3 | 26.5 | 26.6 | SPR028O | 2.5P | 135 | - | 46 | - | 62 | 23 | 17 | 20 | 4 | 013 | f |
| M28X1 | P2 | 27 | 27.09 | SPQ028M | 2.5P | 135 | - | 20 | - | 62 | 23 | 17 | 20 | 4 | 020 | f | |
| M30X3 | P3 | 27 | 27.13 | SPR030S | 2.5P | 135 | - | 46 | - | 62 | 23 | 17 | 20 | 4 | 013 | f | |
| DIES | M30X2 | P3 | 28 | 28.12 | SPR030Q | 2.5P | 135 | - | 46 | - | 62 | 23 | 17 | 20 | 4 | 013 | f |
| M30X1.5 | P3 | 28.5 | 28.6 | SPR030O | 2.5P | 135 | - | 46 | - | 62 | 23 | 17 | 20 | 4 | 013 | f | |
| M30X1 | P2 | 29 | 29.09 | SPQ030M | 2.5P | 135 | - | 21 | - | 62 | 23 | 17 | 20 | 4 | 020 | f | |
| CENTER | M32X3 | P3 | 29 | 29.13 | SPMR032S | 2.5P | 145 | - | 46 | - | 67 | 24 | 19 | 22 | 4 | 013 | f |
| DRILLS | M32X2 | P3 | 30 | 30.12 | SPMR032Q | 2.5P | 145 | - | 46 | - | 67 | 24 | 19 | 22 | 4 | 013 | f |
| M32X1.5 | P3 | 30.5 | 30.6 | SPMR032O | 2.5P | 145 | - | 46 | - | 67 | 24 | 19 | 22 | 4 | 013 | f |
