h stock standard, ) check stock EU, f check stock JP, m stock exhaustion M TCTR Ø Hole Ø Code THCHT LF LT THL LU LS DCON K LK NOF Type Stock Intro (tolerance) (mm) (mm) (chamfer) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) DIN YMW M6X1 ISO2X(6HX) 5 5.09 SY6.0MBLDTHZ 2.5P 80 - 15 30 45 6 4.9 8 3 076 h M8X1.25 ISO2X(6HX) 6.8 6.85 SY8.0NBLDTHZ 2.5P 90 - 19 35 48 8 6.2 9 3 076 h SP M10X1.5 ISO2X(6HX) 8.5 8.6 SY010OBLDTHZ 2.5P 100 - 23 39 53 10 8 11 3 076 h DIN M12X1.75 ISO2X(6HX) 10.3 10.36 SY012PBLDTHZ 2.5P 110 - 26 44 57 12 9 12 3 076 h MF TCTR Ø Hole Ø THCHT LF LT THL LU LS DCON K LK (tolerance) (mm) (mm) Code (chamfer) (mm) (mm) (mm) (mm) (mm) (mm) (mm) (mm) NOF Type Stock SL DIN YMW M10X1.25 ISO2X(6HX) 8.8 8.85 SY010NBLDTHZ 2.5P 100 - 23 39 53 10 8 11 3 076 f M12X1.5 ISO2X(6HX) 10.5 10.6 SY012OBLDTHZ 2.5P 110 - 26 44 57 12 9 12 3 076 f PO M12X1.25 ISO2X(6HX) 10.8 10.85 SY012NBLDTHZ 2.5P 110 - 26 44 57 12 9 12 3 076 f ST ROLL CARBIDE LONG HAND TAPS EG (STI) SPECIAL THREADS, GAUGES THREAD MILLS DIES CENTER DRILLS Technical info 155
