Solid Carbide Endmills G550 - Long Shank Square Type - 4F 㜃汣䧻幹▗捠。搠⎏ . 朆㥓⤚ .!4 ⎒ ᅚ 81,&2&RDWLQJSURYLGHVVXSHULRUZHDUUHVLVWDQFHDQGUHGXFHVWKHFRHႈFLHQWRIIULFWLRQ Solid Carbide Endmills ᅚ Suitable for HRC 30 to HRC 55 Ordinary Steel, Alloy Steel, Cast Iron, Heat-Resistant Steel, etc. ᅚ Available in various length of cut and overall length end mills. ᅚ Flat design to avoid chipping of the cutting tip. EPSEC Order No. Dia. CL OAL Shank Flutes EPSKC 宑庋佷䩋 (d) (L1) (L) (D) (F) EPSLC EPSEC403000U 3 8 75 4 4 EPSNC EPSKC403000U 3 8 100 4 4 EPSJC404000U 4 10 60 4 4 EPSEC404000U 4 10 75 4 4 EPSKC404000U 4 10 100 4 4 EPSMC404000U 4 10 60 6 4 d EPSLC404000U 4 10 75 6 4 EPSNC404000U 4 10 100 6 4 EPSMC406000U 6 15 60 6 4 L1 EPSLC406000U 6 15 75 6 4 EPSNC406000U 6 15 100 6 4 EPSMC408000U 8 20 75 8 4 EPSLC408000U 8 20 100 8 4 EPSNC408000U 8 20 150 8 4 L EPSLC410000U 10 25 100 10 4 EPSNC410000U 10 25 150 10 4 EPSLC412000U 12 30 100 12 4 EPSNC412000U 12 30 150 12 4 EPSLC416000U 16 40 150 16 4 EPSLC420000U 20 40 150 20 4 D 30° Cutting conditions) ら峿⎖⏙╒㜇姷 * : Table 032 d Tolerance Ø<3 0 ~ -0.03 3 Ŝ Ø Ŝ 10 0 ~ -0.04 Ø > 10 0 ~ -0.05 SA085
