Solid Carbide Endmills G550 - Square Type - 2F 㜃汣䧻幹▗捠。搠⎏ . 㮨䀥⤚ .!2 ⎒ ᅚ 81,&2&RDWLQJSURYLGHVVXSHULRUZHDUUHVLVWDQFHDQGUHGXFHVWKHFRHႈFLHQWRIIULFWLRQ ᅚSuitable for HRC 30 to HRC 55 Ordinary Steel, Alloy Steel, Cast Iron, Heat-Resistant Steel,etc. ᅚStrong geometry design has excellent cutting ability of cutting edges. ᅚHigh precision cutting for side milling. Order No. Dia. CL OAL Shank Flutes 宑庋佷䩋 (d) (L1) (L) (D) (F) EPSSC EPSFC200200U 0.2 0.4 50 4 2 EPSFC200300U 0.3 0.6 50 4 2 EPSFC200400U 0.4 0.8 50 4 2 EPSFC200500U 0.5 1.0 50 4 2 EPSFC200600U 0.6 1.5 50 4 2 EPSFC200700U 0.7 2.0 50 4 2 d EPSFC200800U 0.8 2.0 50 4 2 EPSFC200900U 0.9 2.0 50 4 2 EPSFC201000U 1.0 3.0 50 4 2 L1 EPSFC201500U 1.5 4.0 50 4 2 EPSFC202000U 2.0 5.0 50 4 2 EPSFC202500U 2.5 6.0 50 4 2 EPSFC203000U 3.0 8.0 50 4 2 EPSFC203500U 3.5 9.0 50 4 2 L EPSFC204000U 4.0 10.0 50 4 2 EPSSC201000U 1.0 3.0 50 6 2 EPSSC202000U 2.0 5.0 50 6 2 EPSSC203000U 3.0 8.0 50 6 2 EPSSC203500U 3.5 9.0 50 6 2 EPSSC204000U 4.0 10.0 50 6 2 EPSSC204500U 4.5 11.0 50 6 2 EPSSC205000U 5.0 13.0 50 6 2 D EPSSC205500U 5.5 14.0 50 6 2 EPSSC206000U 6.0 15.0 50 6 2 EPSSC206500U 6.5 16.0 60 8 2 EPSSC207000U 7.0 18.0 60 8 2 EPSSC208000U 8.0 20.0 60 8 2 EPSSC209000U 9.0 22.0 75 10 2 EPSSC210000U 10.0 25.0 75 10 2 EPSSC211000U 11.0 25.0 75 12 2 EPSSC212000U 12.0 30.0 75 12 2 EPSSC214000U 14.0 30.0 75 14 2 EPSSC216000U 16.0 35.0 100 16 2 d Tolerance EPSSC218000U 18.0 40.0 100 20 2 Ø<3 0 ~ -0.02 EPSSC220000U 20.0 45.0 100 20 2 3 Ŝ Ø Ŝ 10 0 ~ -0.03 EPSSC225000U 25.0 45.0 100 25 2 Ø > 10 0 ~ -0.04 Cutting conditions) ら峿⎖⏙╒㜇姷 * : Table 027 SA078
