Solid Carbide Endmills ET - Thread milling 㜃汣䧻幹▗捠搠䏨⎏ Ψ ETMNM Series Solid Carbide Endmills L1 d D L Tolerance class : 6H Order No. No. of Dia. CL OAL Shank Flutes Size Pitch 宑庋佷䩋 Threads (d) (L1) (L) (D) (F) ETMNM30390100S 1.00 12 3.90 12.00 50 6 3 M6 ETMNM30390075S 0.75 16 3.90 12.00 50 6 3 ETMNM30580125S 1.25 13 5.80 16.25 60 6 3 M8 ETMNM30590100S 1.00 16 5.90 16.00 60 6 3 ETMNM30770150S 1.50 14 7.70 21.00 60 8 3 ETMNM30770125S M10 1.25 16 7.70 20.00 60 8 3 ETMNM30790100S 1.00 20 7.90 20.00 60 8 3 ETMNM40870175S 1.75 14 8.70 24.50 75 10 4 ETMNM40940150S M12 1.50 16 9.40 24.00 75 10 4 ETMNM40990100S 1.00 24 9.90 24.00 75 10 4 ETMNM40990200S 2.00 14 9.90 28.00 75 10 4 M14 ETMNM41120150S 1.50 19 11.20 28.50 75 12 4 ETMNM41190200S 2.00 16 11.90 32.00 100 12 4 M16 ETMNM41190150S 1.50 22 11.90 33.00 100 12 4 ρ &XVWRPL]HRWKHUVSHFL¿FDWLRQDYDLODEOH Ψ ETMCM Series L1 d D L Tolerance class : 6H Order No. No. of Dia. CL OAL Shank Flutes Size Pitch 宑庋佷䩋 Threads (d) (L1) (L) (D) (F) ETMCM30390100S 1.00 12 3.90 12.00 50 6 3 M6 ETMCM30390075S 0.75 16 3.90 12.00 50 6 3 ETMCM30580125S 1.25 13 5.80 16.25 60 6 3 M8 ETMCM30590100S 1.00 16 5.90 16.00 60 6 3 ETMCM30770150S 1.50 14 7.70 21.00 60 8 3 ETMCM30770125S M10 1.25 16 7.70 20.00 60 8 3 ETMCM30790100S 1.00 20 7.90 20.00 60 8 3 ETMCM40870175S 1.75 14 8.70 24.50 75 10 4 ETMCM40940150S M12 1.50 16 9.40 24.00 75 10 4 ETMCM40990100S 1.00 24 9.90 24.00 75 10 4 ETMCM40990200S 2.00 14 9.90 28.00 75 10 4 M14 ETMCM41120150S 1.50 19 11.20 28.50 75 12 4 ETMCM41190200S 2.00 16 11.90 32.00 100 12 4 M16 ETMCM41190150S 1.50 22 11.90 33.00 100 12 4 ρ &XVWRPL]HRWKHUVSHFL¿FDWLRQDYDLODEOH Cutting conditions) ら峿⎖⏙╒㜇姷 * : Table 070 SA191
