Indexable Milling Tools
CXLN High Feed Face Milling 汧懁仵。棱搠⏙

,QVHUW6SHFL¿FDWLRQV
Dimensions (mm)
Insert
A B S d1

LNMX0303 11.59 6.0 4.29 2.85


Order Code
Order No. Working Material
Insert 宑庋佷䩋
Designation
P M K N S H
ILNMX0303SG22HS LNMX0303-SG-CX22HS β ΰ β ΰ β
ILNMX0303SG32HS LNMX0303-SG-CX32HS β β β ΰ ΰ

ILNMX0303MG22HS LNMX0303-MG-CX22HS β ΰ β ΰ β
ILNMX0303MG32HS LNMX0303-MG-CX32HS β β β ΰ ΰ
ILNMX0303MG43TS LNMX0303-MG-CX43TS β β β β


Corner R Programming
Approx. R (mm)
Designation
Input. R Uncut
LNMX0303 1.5 0.5


IA088
