Indexable Milling Tools
CARD Copy Milling ₎ヱ搠⏙

Insert Order Code
Order No. Working Material
Insert 宑庋佷䩋
Designation
P M K N S H
IRDMT1204MOT22HS RDMT1204MOT-CX22HS β ΰ β ΰ β
IRDMT1204MOT32HS RDMT1204MOT-CX32HS β β β ΰ ΰ
IRDMT1204MOT43TS RDMT1204MOT-CX43TS β β β β
IRDMW1204MOT22HS RDMW1204MOT-CX22HS β ΰ β ΰ β
IRDMW1204MOT32HS RDMW1204MOT-CX32HS β β β ΰ ΰ
IRDMW1204MOT43TS RDMW1204MOT-CX43TS β β β β
IRDMT1604MOT22HS RDMT1604MOT-CX22HS β ΰ β ΰ β
IRDMT1604MOT32HS RDMT1604MOT-CX32HS β β β ΰ ΰ
IRDMT1604MOT43TS RDMT1604MOT-CX43TS β β β β
IRDMW1604MOT22HS RDMW1604MOT-CX22HS β ΰ β ΰ β
IRDMW1604MOT32HS RDMW1604MOT-CX32HS β β β ΰ ΰ
IRDMW1604MOT43TS RDMW1604MOT-CX43TS β β β β


Recommended Cutting Conditions
'LD” Dia > 10
Working Material Vc
fz ap fz ap
Carbon Steel (HB85-225) 120 ~ 250 0.1 ~ 0.6 0.3 ~ 1.5 0.2 ~ 0.8 0.5 ~ 2.5
Stainless 300 Series 100 ~ 180 0.08 ~ 0.4 0.3 ~ 1.2 0.15 ~ 0.4 0.5 ~ 2.0
Cast Iron (HB140-220) 120 ~ 250 0.1 ~ 0.6 0.3 ~ 1.5 0.2 ~ 0.8 0.5 ~ 2.5
High temp. & Titanium alloy 40 ~ 100 0.08 ~ 0.3 0.3 ~ 1.0 0.15 ~ 0.3 0.3 ~ 2.0
Hardened steel 50 ~ 100 0.08 ~ 0.3 0.3 ~ 1.0 0.15 ~ 0.3 0.3 ~ 2.0


IA070
