Turning Tools Internal Turning Tools ⋶ㄠ恙⎏㨎 MWLN Order No.宑庋佷䩋 Dimensions, mm Insert Shim Pin Wrench Clamp Screw WrenchDLL1fHKdmin IS20R-MWLNR/L-08 20 200 36 13 18 15 25 -- IMLP44-A IMS520TX IS25R-MWLNR/L-08 25 200 40 15 23 13 30 IMC515 IETL10 IS32S-MWLNR/L-08 32 250 48 20 30 13 40 IMS520TX IS40T-MWLNR/L-08 40 300 55 25.5 37 10 50 IWMS432 IMLP46-A IS50U-MWLNR/L-08 50 350 60 30.5 47 9 60 WN..0804.. IPL25 IMC620 IMS625TX IETL15 IS60V-MWLNR/L-08 60 400 60 35.5 57 8 70 IA20R-MWLNR/L-08 20 200 36 13 18 15 25 -- IMLP44-A IMS520TX IA25R-MWLNR/L-08 25 200 40 15 23 13 30 IMC515 IETL10 IA32S-MWLNR/L-08 32 250 48 20 30 13 40 IWMS432 IMLP46-A IMS520TX DWLN Order No.宑庋佷䩋 Dimensions, mm Insert Shim Screw Wrench Clamp WrenchDLL1fHKdmin IS20R-DWLNR/L-08 20 200 40 14 18 15 28 WN..0804.. -- -- -- IMCD425 IETL20 IS25R-DWLNR/L-08 25 200 40 15 23 13 30 IC028
