  • Insert Selection Guide
MaterialLig Machht iningGen Purperal oseHe Machavy ining
GroupGeometryGradeGeometryGradeGeometryGrade
P1–P2MMTN6525MMTN6525MMTN6540
P3–P4MHTN2505MHTN6525MHTN6540
P5–P6MHTN2505MHTN6525MHTN6540
M1–M2––MMTN6525MMTN6540
M3––MMTN6525MMTN6540
K1–K2MHTN2505MHTN2505MHTN6525
K3MHTN2505MHTN2505MHTN6525
N1–N2––––––
N3––––––
S1–S2––MMTN6540––
S3––MMTN6540––
S4––MMTN6540––
H1MHTN2505MHTN2505––

iC10 Inserts

fi rst choice

RDPX-MM RDPX-MH alternate choice

  • -MM geometry is the best option for general-purpose use, materials, and applications. Used for reduced cutting forces.
  • RDPX-MM

P M K N S H

catalogue numberDShm
RDPX1003M0SNMM10,003,180,11
  • -MH geometry is the fi rst choice for heavy machining.
  • Suitable for high-strength steels, cast iron, and hard machining.
  • RDPX-MH
catalogue numberDShm
RDPX1003M0SNMH10,003,180,12
