Threading Application Guide

Laydown Square Shank Toolholder Sizes: Cresting (Full Profi le):

• Metric — 8–40mm UN 48–8 TPI

External Threading ISO 0,5–5,0mm pitch

60° Partial Profi le: UN 48–4 TPI ISO 0,5–6,0mm pitch

Laydown Boring Bar Diameters: Cresting (Full Profi le)

• Metric — 12–50mm and Partial Profi le:

Internal Threading Minimum bore — (13mm) UN 48–8 TPI

• Steel and carbide ISO 0,5–5,0mm pitch

60° Partial Profi le: UN 48–4 TPI ISO 0,5–6,0mm pitch

55° Partial Profi le: UN 48–5 TPI ISO 0,5–5,0mm pitch
