S² Ultra Inserts
Neutral, RL = RR
Right Hand
S² Ultra
Left Hand
first choice alternate choice
P M K N S H
insert
| catalogue number | size | W | RR | hand | |
| 507329 | 2 | 2,39 | 0,15 | N - Neutral |
507332 3 3,18 0,15 N - Neutral
insert
| catalogue number | size | W | RR | _L | hand | |
| 507331 | 2 | 2,39 | 0,15 | 5 | L - Left |
507334 3 3,18 0,15 5 L - Left
insert
| catalogue number | size | W | RL | _R | hand | |
| 507330 | 2 | 2,39 | 0,15 | 5 | R - Right |
507333 3 3,18 0,15 5 R - Right
