Custom Order Worksheet
TopGroove Grooving Systems
Use this Custom Order Worksheet to modify an existing product to meet Trust our experienced distributors and WIDIA engineering team to design the your specifi cations. If your custom requirements do not fall into these best solution for you. categories, simply contact your WIDIA™ Distributor.
Date
Customer-Specifi ed Dimensions
Style (circle one) A B1 B2 B3 B4 C1 D F G
Orientation (circle one) left hand right hand
Top Rake Total Width (T)
| Cutting Width (W) | Angle 1 | ||
| Corner Radius 1 (R1) | Angle 2 | ||
| Corner Radius 2 (R2) | Offset (H) | ||
| Cutting Depth (E1) | Other (please specify) |
Special Instructions (please make any necessary notes or sketches in the box at right)
Closest Catalogue Standard
Customer
Distributor
Shipping Requirements
Attention Distributors: Use this worksheet to collect information for your customer.
U Ground U Next Day Air U 2nd Day Air U 3rd Day Air
