Small Hole Boring Bars for Grooving and Threading
CSMM
gage insert
| order number | catalogue number | D | D min | D2 | F | L1 | A | aF° | aP° | insert | screw | Torx | ||
| right hand | ||||||||||||||
| 2831048 | CSMM6760R | 6,00 | 7,92 | 6,60 | 4,44 | 76,20 | 1,02 | 0.0° | 0.0° | CD.50302R | CC11 | T6 |
NOTE: Refer to insert design for cutting depth, cutting width, and blind hole limitations.
