(TDG532A • 5 x D — continued)
first choice alternate choice
| WN10HD grade WN10HD | ||||||||
| order # catalogue # | mm | in | L | L4 max | L3 | L5 | LS | D |
| 4158618 TDG532A19800 | 19,800 | .7795 | 153 | 77 | 101 | 4,6 | 50 | 20 |
| 4158620 TDG532A19900 | 19,900 | .7835 | 153 | 77 | 101 | 4,6 | 50 | 20 |
| 4158622 TDG532A20000 | 20,000 | .7874 | 153 | 77 | 101 | 4,7 | 50 | 20 |
| 4158634 TDG532A21000 | 21,000 | .8268 | 167 | 85 | 114 | 4,9 | 50 | 20 |
| 4158636 TDG532A22000 | 22,000 | .8661 | 167 | 85 | 114 | 5,1 | 50 | 20 |
| 4158637 TDG532A23000 | 23,000 | .9055 | 184 | 98 | 126 | 5,4 | 56 | 25 |
