WIDIA™ VariTurn™ Inserts P         M      first choice K       alternate choice N   Inserts S     H „ CNMG-6P TN15M TN30M TN10U TN15U TN20K TN10P TN20P TN30P ISO catalogue number D L10 S R¡ D1 4165948 4165949 4165950 4165951 CNMG0903086P 9,53 9,67 3,18 0,8 3,81 – – – – 4165952 4165963 4165964 4165965 CNMG1204046P 12,70 12,90 4,76 0,4 5,16 – – – – 4165966 4165967 4165968 4165969 4165970 CNMG1204086P 12,70 12,90 4,76 0,8 5,16 – – – 4165971 4165972 4165973 4165974 4165975 CNMG1204126P 12,70 12,90 4,76 1,2 5,16 – – – 4165976 4165977 4165978 4165979 CNMG1606126P 15,88 16,12 6,35 1,2 6,35 – – – – 4165980 4165981 4165982 4165983 CNMG1906126P 19,05 19,34 6,35 1,2 7,93 – – – – B127 C2–C49 C50–C81 C86–C129 B8–B25 B26–B28 B30–B105 WID_Master16_Turning_Inserts_B126_B127_Metric_REBRAND.indd 127 L V i WID M 16 T i I B126 B127 M i REBRANDO b 1520159 10/30/15 38AM 2:50 PM
