  • Centre cutting.
  • Standard items listed. Additional styles and coatings made-to-order.
End Mill Tolerances
D1tolerance e8Dtolerance h6 + / -
�3-0,014/-0,028�30/0,006
> 3–6-0,020/-0,038> 3–60/0,008
> 6–10-0,025/-0,047> 6–100/0,009
> 10–18-0,032/-0,059> 10–180/0,011
> 18–30-0,040/-0,073> 18–300/0,013

„ Series 75N2 Vision Plus

first choice alternate choice

grade TiAlN-RT1TiAlN - RT1

TiAlN - RT1 grade TiAlN-RT1 TiAlN order # catalogue #D1DD3length of cut Ap1 maxL3length LR �
2544530 75N203022RT3,062,803,009,00750,30
2544735 75N203042RT3,062,803,009,00750,50
2544736 75N203062RT3,062,803,009,00751,00
2544737 75N204022RT4,063,704,0012,00750,30
2544738 75N204042RT4,063,704,0012,00750,50
2544739 75N204062RT4,063,704,0012,00751,00
2544740 75N205022RT5,064,605,0015,00750,30
2544741 75N205042RT5,064,605,0015,00751,00
2544742 75N206032RT6,065,506,0018,00750,30
2545163 75N206042RT6,065,506,0018,00750,50
2545164 75N206052RT6,065,506,0018,00750,75
2545166 75N206062RT6,065,506,0018,00751,00
2545167 75N206072RT6,065,506,0018,00751,50
2545168 75N208023RT8,087,408,0024,001000,50
2545169 75N208043RT8,087,408,0024,001001,00
2545170 75N208063RT8,087,408,0024,001001,50
2545171 75N210024RT10,0109,2010,0030,001000,50
2545172 75N210034RT10,0109,2010,0030,001000,75
2545183 75N210044RT10,0109,2010,0030,001001,00
2545184 75N210064RT10,0109,2010,0030,001002,00
2545185 75N212025RT12,01211,0012,0036,001250,50
2545186 75N212035RT12,01211,0012,0036,001250,75
2545187 75N212045RT12,01211,0012,0036,001251,00
2545188 75N212055RT12,01211,0012,0036,001251,50
2545189 75N212065RT12,01211,0012,0036,001252,00
