Series 4717 VariMill I™ Extended Length of Cut

  • Unequal flute spacing.
  • Centre cutting.
  • Standard items listed. Additional styles and coatings made-to-order.
End Mill Tolerances
D1tolerance e8Dtolerance h6 + / -
�3-0,014/-0,028�30/-0,006
> 3-6-0,020/-0,038> 3–60/-0,008
> 6–10-0,025/-0,047> 6–100/-0,009
> 10–18-0,032/-0,059> 10–180/-0,011
> 18–30-0,040/-0,073> 18–300/-0,013

„ Series 4717 VariMill Extended Length of Cut

first choice alternate choice

grade TiAlN-LWTiAlN-LW TiAlN

TiAlN-LW grade TiAlN-LW TiAlN order # catalogue #D1Dlength of cut Ap1 maxlength LBCH
3641112 471706002LW6,0632,00760,40
3641113 471708003LW8,0832,00870,40
3641114 471710004LW10,01038,00890,50
3641115 471712005LW12,01251,001000,50
3641116 471716006LW16,01657,001250,50
3641117 471720007LW20,02057,001250,50
