D1
CS MM-BT Form AD
| lock | wrench size | combi | combi | |||||||
| order number | catalog number | D1 D2 L1 | L13 | screw | lock screw | driver ring | drive key | kg | ||
| 1191713 | BT40CS16055M | 16 32 | 55 | 27 | MS1294 | 6mm | CDR16M | CDK16M | 1,15 | |
| 1191714 | BT40CS16100M | 16 32 100 | 27 | MS1294 | 6mm | CDR16M | CDK16M | 1,41 | ||
| 1191715 | BT40CS22055M | 22 40 | 55 | 31 | MS1234 | 8mm | CDR22M | CDK22M | 1,28 | |
| 1191716 | BT40CS22150M | 22 40 150 | 31 | MS1234 | 8mm | CDR22M | CDK22M | 2,16 |
CS Lock MM-BT Form AD
| lock | lock screw | combi | combi | |||||||
| order number | catalog number | D1 D2 L1 L13 | screw | wrench | driver ring | drive key | kg | |||
| 1191717 | BT40CS27055M | 27 48 | 55 | 33 | KLS27MPKG | SMW27M | CDR27M | CDK27M | 1,47 | |
| 1191718 | BT40CS27150M | 27 48 150 33 | KLS27MPKG | SMW27M | CDR27M | CDK27M | 2,73 | |||
| 1191719 | BT40CS32060M | 32 58 | 60 | 38 | KLS32M | SMW32M | CDR32M | CDK32M | 1,80 | |
| 1191720 | BT40CS32150M | 32 58 150 38 | KLS32M | SMW32M | CDR32M | CDK32M | 3,62 | |||
| 1191721 | BT40CS40080M | 40 70 | 80 | 41 | KLS40M | SMW40M | CDR40M | CDK40M | 2,75 |
NOTE: Do not overtighten lock screw. Supplied with lock screw, combi drive ring, and drive keys. Lock screw wrench not included. For retention knobs, see page J33.
