HPMC MM-BT Form AD
locknut stop wrench size
| order number | catalog number | D1 | D11 | L1 | L9 | V | wrench | screw | stop screw | kg | ||
| 3578486 | BT30HPMC20085M | 20 | 53 | 85 | 55 | 20 | PSW52M | MCSS12030M | 2,5mm & 5mm | 1,00 |
HPMC IN-BT Form AD
locknut stop wrench size
| order number | catalog number | D1 | D11 | L1 | L9 | V | wrench | screw | stop screw | lbs | ||
| 3100411 | BT30HPMC075335 | 3/4 2.09 3.35 2.17 .59 | PSW52M | MCSS12030M | 2,5mm & 5mm | 2.50 |
NOTE: Milling chuck technical section, see page K64. Supplied with locknut and stop screw. Locknut wrench not included. Optional M6~1,0P fine-balancing screw set is available (order number HPMCBALSCREWSET) and must be ordered separately;
see page J4. Reduction sleeves are available and must be ordered separately; see page I6. For retention knobs, see page J33.
