KM50TS Cutting Units KM50TS™ Cutting Units M-Clamping Centerline • P-Clamping Left-Hand Tool MWMN 50° • 95° Application • Centerline L1 F gage lock clamp order number catalog number mm in mm in insert shim pin clamp screw kg lbs right hand 3738598 KM50TSMWMNR08 50 1.969 0 .000 WN..080408/WN..432 IWSN433 KLM46 CKM20LP STCM11 0,49 1.08 left hand 3738597 KM50TSMWMNL08 50 1.969 0 .000 WN..080408/WN..432 IWSN433 KLM46 CKM20LP STCM11 0,49 1.08 NOTE: Use the KM63TSS5065 reducer to produce an L1 of 115mm. PCKN 75° L1 F D min gage lever shim toggle order number catalog number mm in mm in mm in insert shim screw pin lever punch kg lbs right hand 3738514 KM50TSPCKNR12 50 1.969 35 1.378 63 2.480 CN..120408/CN..432 512.112 514.123 513.023 511.023 515.018 0,68 1.50 left hand 3738513 KM50TSPCKNL12 50 1.969 35 1.378 63 2.480 CN..120408/CN..432 512.112 514.123 513.023 511.023 515.018 0,68 1.50 A130 WWW.WIDIA.COM
