TNMG-UF
v first choice j alternate choice
| P | j |
| M | v |
| K | j |
| N | j |
| S | v |
H
ISO
| catalogue number | D | L10 | S | Re | D1 |
| TNMG160404UF | 9,53 | 16,50 | 4,76 | 0,4 | 3,81 |
TNMG-UM
v first choice j alternate choice
| P | j j | |
| M | v v | |
| K | j | |
| N | j | |
| S | j v |
H
ISO
| catalogue number | D | L10 | S | Re | D1 |
| TNMG160404UM | 9,53 | 16,50 | 4,76 | 0,4 | 3,81 |
TNMG160408UM 9,53 16,50 4,76 0,8 3,81
THE ALL-STAR PROGRAMME FEATURES ONLY THE MOST POPULAR PLATFORMS, GRADES, AND SIZES. FOR THE COMPLETE OFFERING, VISIT WIDIA NOVO ™ OR WIDIA.COM.
