TNMG-ML
| vfirst choice jalternate ch | P v v j M K j j v N S H oice | |||||
| ISO catalogue number | D | L10 | S | R e | D1 | WP15CT WP25CT WK20CT |
| TNMG160404ML | 9,53 | 16,50 | 4,76 | 0,4 | 3,81 | 4171075 4170491 – |
| TNMG160408ML | 9,53 | 16,50 | 4,76 | 0,8 | 3,81 | 4171076 4170492 4171410 |
| TNMG160412ML | 9,53 | 16,50 | 4,76 | 1,2 | 3,81 | 4171077 – – |
TNMG-MR
| vfi ja | irst choice lternate choic | P M K N S H e | v v j j | ||||
| ISO catalogue number | D | L10 | S | R e | D1 | WP15CT WP25CT | |
| TNMG160404MR | 9,53 | 16,50 | 4,76 | 0,4 | 3,81 | 4171150 4170573 | |
| TNMG160408MR | 9,53 | 16,50 | 4,76 | 0,8 | 3,81 | 4171151 4170574 | |
| TNMG160412MR | 9,53 | 16,50 | 4,76 | 1,2 | 3,81 | 4171152 – |
