Ap1 max
| order | catalogue | D1 | D | L | L2 | max | ramp | max | coolant | ||
| number | number | (mm) | (mm) | (mm) | (mm) | (mm) | Z | angle | RPM | supply | |
| VSM17 • Cylindrical End Mills • Long Shank | |||||||||||
| 5988108 | VSM17D032Z02A32XD17L210 | 32 | 32 | 210 | 50 | 16,3 | 2 | 5.7 | 34700 | Yes | |
| 5988058 | VSM17D032Z03A32XD17L210 | 32 | 32 | 210 | 50 | 16,3 | 3 | 5.7 | 34700 | Yes | |
| 5988110 | VSM17D040Z03A32XD17L250 | 40 | 32 | 250 | 50 | 16,2 | 3 | 4.0 | 29800 | Yes | |
| 5988060 | VSM17D040Z04A32XD17L250 | 40 | 32 | 250 | 50 | 16,2 | 4 | 4.0 | 29800 | Yes |
Ap1 max
| order | catalogue D1 | D | D6 | L | max | ramp | max | coolant | ||
| number | number (mm) | (mm) | (mm) | (mm) | (mm) | Z | angle | RPM | supply | |
| VSM17 • Shell Mills | ||||||||||
| 5988094 | VSM17D040Z04S16XD17 | 40 | 16 | 37 | 40 | 16,2 | 4 | 4.0 | 29800 | Yes |
| 5988095 | VSM17D050Z04S22XD17 | 50 | 22 | 45 | 40 | 16,1 | 4 | 3.0 | 25800 | Yes |
| 5988096 | VSM17D050Z05S22XD17 | 50 | 22 | 45 | 40 | 16,1 | 5 | 3.0 | 25800 | Yes |
| 5988134 | VSM17D050Z06S22XD17 | 50 | 22 | 45 | 40 | 16,1 | 6 | 3.0 | 25800 | Yes |
| 5988097 | VSM17D063Z05S22XD17 | 63 | 22 | 50 | 40 | 16,0 | 5 | 2.1 | 22400 | Yes |
| 5988135 | VSM17D063Z06S22XD17 | 63 | 22 | 50 | 40 | 16,0 | 6 | 2.1 | 22400 | Yes |
| 5988098 | VSM17D080Z06S27XD17 | 80 | 27 | 60 | 50 | 15,9 | 6 | 1.6 | 19500 | Yes |
| 5988133 | VSM17D080Z07S27XD17 | 80 | 27 | 60 | 50 | 15,9 | 7 | 1.6 | 19500 | Yes |
| 5988099 | VSM17D100Z08S32XD17 | 100 | 32 | 80 | 50 | 15,8 | 8 | 1.2 | 17200 | Yes |
| 5988100 | VSM17D125Z09S40XD17 | 125 | 40 | 90 | 63 | 15,7 | 9 | 0.9 | 15200 | Yes |
| 5988101 | VSM17D160Z12S40XD17 | 160 | 40 | 100 | 63 | 15,8 | 12 | 0.7 | 13300 | Yes |
