Каталог Widia all star 2019 - страница 51
Навигация
Каталог Widia all star 2020
Каталог Widia токарный инструмент 2017
Каталог Widia достижения 2018
Каталог Widia достижения 2017
Брошюра Widia техническое руководство
Ap1 max
| order | catalogue | D1 | D | DPM | G3X | L2 | WF | max | ramp | max | coolant | ||
| number | number | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | Z | angle | RPM | supply | |
| VSM17 • Screw-On End Mills | |||||||||||||
| 5988091 | VSM17D025Z02M12XD17 | 25 | 21 | 12,5 | M12 | 35 | 17 | 16,4 | 2 | 8.8 | 41800 | Yes | |
| 5988092 | VSM17D032Z03M16XD17 | 32 | 29 | 17,0 | M16 | 40 | 24 | 16,3 | 3 | 5.7 | 34700 | Yes | |
| 5988131 | VSM17D40Z03M016XD17 | 40 | 29 | 17,0 | M16 | 40 | 24 | 16,2 | 3 | 4.0 | 29800 | Yes | |
| 5988093 | VSM17D040Z04M16XD17 | 40 | 29 | 17,0 | M16 | 40 | 24 | 16,2 | 4 | 4.0 | 29800 | Yes |
Ap1 max
| order | catalogue | D1 | D | L | L2 | max | ramp | max | coolant | ||
| number | number | (mm) | (mm) | (mm) | (mm) | (mm) | Z | angle | RPM | supply | |
| VSM17 • Weldon® End Mills | |||||||||||
| 5988102 | VSM17D025Z02B25XD17 | 25 | 25 | 90 | 33 | 16,4 | 2 | 8.8 | 41800 | Yes | |
| 5988103 | VSM17D032Z03B32XD17 | 32 | 32 | 100 | 39 | 16,3 | 3 | 5.7 | 34700 | Yes | |
| 5988104 | VSM17D040Z04B40XD17 | 40 | 40 | 110 | 39 | 16,2 | 4 | 4.0 | 29800 | Yes |
Ap1 max
| order | catalogue | D1 | D | L | L2 | max | ramp | max | coolant | ||
| number | number | (mm) | (mm) | (mm) | (mm) | (mm) | Z | angle | RPM | supply | |
| VSM17 • Cylindrical End Mills | |||||||||||
| 5988055 | VSM17D025Z02A25XD17L110 | 25 | 25 | 110 | 44 | 16,4 | 2 | 8.8 | 41800 | Yes | |
| 5988056 | VSM17D025Z02A25XD17L170 | 25 | 25 | 170 | 44 | 16,4 | 2 | 8.8 | 41800 | Yes | |
| 5988107 | VSM17D032Z02A32XD17L120 | 32 | 32 | 120 | 50 | 16,3 | 2 | 5.7 | 34700 | Yes | |
| 5988057 | VSM17D032Z03A32XD17L120 | 32 | 32 | 120 | 50 | 16,3 | 3 | 5.7 | 34700 | Yes | |
| 5988109 | VSM17D040Z03A32XD17L130 | 40 | 32 | 130 | 50 | 16,2 | 3 | 4.0 | 29800 | Yes | |
| 5988059 | VSM17D040Z04A32XD17L130 | 40 | 32 | 130 | 50 | 16,2 | 4 | 4.0 | 29800 | Yes |
