Ap1
| order | catalogue | D1 | D1 max | D | D6 | L | max | max | coolant | ||
| number | number | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | Z | RPM | supply | |
| Victory™ M1200 HF • Shell Mills | |||||||||||
| 3750370 | M1200HF050Z04HN09 | 50 | 67,9 | 22 | 38 | 40 | 2,2 | 4 | 11400 | Yes | |
| 3750372 | M1200HF063Z05HN09 | 63 | 80,9 | 22 | 50 | 40 | 2,2 | 5 | 8950 | Yes | |
| 3750434 | M1200HF080Z06HN09 | 80 | 97,9 | 27 | 60 | 50 | 2,2 | 6 | 7300 | Yes | |
| 3750435 | M1200HF100Z08HN09 | 100 | 117,9 | 32 | 80 | 50 | 2,2 | 8 | 5900 | Yes |
Ap1
| order | catalogue | D1 | D1 max | D | L | L2 | max | max | coolant | |||
| number | number | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | Z | RPM | supply | ||
| Victory M1200 • Weldon ® Shank | ||||||||||||
| 3325311 | M1200D040Z04B25HN09 | 40 | 51,0 | 25 | 107 | 50 | 4,5 | 4 | 15800 | Yes |
D1 Ap1
| order | catalogue D1 | max | D | D4 | D6 | L | max | max | coolant | ||
| number | number (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | Z | RPM | supply | |
| Victory M1200 • Shell Mills | |||||||||||
| 3957970 | M1200D040Z03HN09 | 40 | 51,0 | 22 | – | 39 | 40 | 4,4 | 3 | 15800 | Yes |
| 3957971 | M1200D040Z04HN09 | 40 | 51,0 | 22 | – | 39 | 40 | 4,4 | 4 | 15800 | Yes |
| 3325312 | M1200D050Z04HN09 | 50 | 61,0 | 22 | – | 38 | 40 | 4,5 | 4 | 12700 | Yes |
| 3325693 | M1200D050Z05HN09 | 50 | 61,0 | 22 | – | 38 | 40 | 4,5 | 5 | 12700 | Yes |
| 3650535 | M1200D063Z04HN09 | 63 | 74,0 | 22 | – | 50 | 40 | 4,5 | 4 | 10100 | Yes |
| 3093594 | M1200D063Z06HN09 | 63 | 74,0 | 22 | – | 50 | 40 | 4,5 | 6 | 10100 | Yes |
| 3025376 | M1200D063Z07HN09 | 63 | 74,0 | 22 | – | 50 | 40 | 4,5 | 7 | 10100 | Yes |
| 3650536 | M1200D080Z05HN09 | 80 | 91,0 | 27 | – | 60 | 50 | 4,5 | 5 | 7900 | Yes |
| 3081507 | M1200D080Z06HN09 | 80 | 91,0 | 27 | – | 60 | 50 | 4,5 | 6 | 7900 | Yes |
| 3025377 | M1200D080Z09HN09 | 80 | 91,0 | 27 | – | 60 | 50 | 4,5 | 9 | 7900 | Yes |
| 3650537 | M1200D100Z06HN09 | 100 | 111,0 | 32 | – | 80 | 50 | 4,5 | 6 | 6300 | Yes |
| 3325694 | M1200D100Z08HN09 | 100 | 111,0 | 32 | – | 80 | 50 | 4,5 | 8 | 6300 | Yes |
| 3025378 | M1200D100Z11HN09 | 100 | 111,0 | 32 | – | 80 | 50 | 4,5 | 11 | 6300 | Yes |
| 3081508 | M1200D125Z10HN09 | 125 | 135,9 | 40 | – | 90 | 63 | 4,5 | 10 | 5050 | Yes |
| 3066119 | M1200D160Z16HN09 | 160 | 171,0 | 40 | 66,7 | 110 | 63 | 4,5 | 16 | 3900 | Yes |
