| order | catalogue | gage | D | D min | F | L1 | |||||
| number | number | insert | (mm) | (mm) | (mm) | (mm) | CS γF (deg) | ||||
| A-DCLN 95° | |||||||||||
| right hand | |||||||||||
| 5696071 | A25RDCLNR12KC04 | CN.120408 | 25 | 32,0 | 17,0 | 200 | 1/4-18 NPT | -12.0 | |||
| 5696073 | A32SDCLNR12KC04 | CN.120408 | 32 | 40,0 | 22,0 | 250 | 1/4-18 NPT | -12.0 | |||
| left hand | |||||||||||
| 5696072 | A25RDCLNL12KC04 | CN.120408 | 25 | 32,0 | 17,0 | 200 | 1/4-18 NPT | -12.0 | |||
| 5696074 | A32SDCLNL12KC04 | CN.120408 | 32 | 40,0 | 22,0 | 250 | 1/4-18 NPT | -12.0 |
| order | catalogue | gage | D | D min | F | L1 | |||||
| number | number | insert | (mm) | (mm) | (mm) | (mm) | CS γF (deg) | ||||
| A-DDUN 93° | |||||||||||
| right hand | |||||||||||
| 5696211 | A32SDDUNR11KC04 | DN..110408 | 32 | 40,0 | 22,0 | 250 | 1/4-18 NPT | -12.0 | |||
| 5696213 | A32SDDUNR15KC06 | DN..150608 | 32 | 40,0 | 22,0 | 250 | 1/4-18 NPT | -12.0 | |||
| left hand | |||||||||||
| 5696214 | A32SDDUNL15KC06 | DN..150608 | 32 | 40,0 | 22,0 | 250 | 1/4-18 NPT | -12.0 |
| order | catalogue | gage | D | D min | F | L1 | |||||
| number | number | insert | (mm) | (mm) | (mm) | (mm) | CS γF (deg) | ||||
| A-DTFN 90° | |||||||||||
| right hand | |||||||||||
| 5696219 | A25RDTFNR16KC04 | TN..160408 | 25 | 32,0 | 17,0 | 200 | 1/4-18 NPT | -14.0 | |||
| 5696261 | A32SDTFNR16KC04 | TN..160408 | 32 | 40,0 | 22,0 | 250 | 1/4-18 NPT | -12.0 | |||
| left hand | |||||||||||
| 5696260 | A25RDTFNL16KC04 | TN..160408 | 25 | 32,0 | 17,0 | 200 | 1/4-18 NPT | -14.0 |
