| order | catalogue | gage | H | B | F | L1 | CD | |||
| number | number | insert | (mm) | (mm) | (mm) | (mm) | (mm) | |||
| SRDC | ||||||||||
| neutral | ||||||||||
| 3900183 | SRDCN2525M06 | RC..0602M0 | 25 | 25 | 15,0 | 150 | 19,7 | |||
| 3879737 | SRDCN2525M08 | RC..0803M0 | 25 | 25 | 16,5 | 150 | 25,0 | |||
| 3879734 | SRDCN2525M10 | RC..10T3M0 | 25 | 25 | 17,5 | 150 | 25,0 | |||
| 3879738 | SRDCN2525M12 | RC..1204M0 | 25 | 25 | 18,5 | 150 | 25,0 |
| order | catalogue | gage | H | B | F | L1 | L2 | |
| number | number | insert | (mm) | (mm) | (mm) | (mm) | (mm) | |
| SVHB 107,5° | ||||||||
| right hand | ||||||||
| 3879765 | SVHBR2525M16 | VB..160408 | 25 | 25 | 32,0 | 150 | 28,0 | |
| left hand | ||||||||
| 3879766 | SVHBL2525M16 | VB..160408 | 25 | 25 | 32,0 | 150 | 28,0 |
| order | catalogue | gage | H | B | F | L1 | LH | |||
| number | number | insert | (mm) | (mm) | (mm) | (mm) | (mm) | |||
| SVJB 93° | ||||||||||
| right hand | ||||||||||
| 3879775 | SVJBR2525M16 | VB..160408 | 25 | 25 | 32,0 | 150 | 35,0 | |||
| left hand | ||||||||||
| 3879774 | SVJBL2525M16 | VB..160408 | 25 | 25 | 32,0 | 150 | 35,0 |
| order | catalogue | gage | H | B | F | L1 | L2 | |||
| number | number | insert | (mm) | (mm) | (mm) | (mm) | (mm) | |||
| SVVB 72,5° | ||||||||||
| neutral | ||||||||||
| 3879778 | SVVBN2525M16 | VB..160408 | 25 | 25 | 12,5 | 150 | 33,0 |
