| order | catalogue | gage | H | B | F | L1 | LH | B3 | |||
| number | number | insert | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | |||
| DCKN 75° | |||||||||||
| right hand | |||||||||||
| 5697857 | DCKNR2525M12KC04 | CN..120408 | 25 | 25 | 32,0 | 150 | 32,0 | – | |||
| left hand | |||||||||||
| 5697854 | DCKNL2525M12KC04 | CN..120408 | 25 | 25 | 32,0 | 150 | 32,0 | – |
| order | catalogue | gage | H | B | F | L1 | LH | B3 | |||
| number | number | insert | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | |||
| DCLN 95° | |||||||||||
| right hand | |||||||||||
| 5697893 | DCLNR2525M12KC04 | CN..120408 | 25 | 25 | 32,0 | 150 | 32,0 | – | |||
| 5697894 | DCLNR2525M16KC06 | CN..160612 | 25 | 25 | 32,0 | 150 | 33,0 | – | |||
| left hand | |||||||||||
| 5697884 | DCLNL2525M12KC04 | CN..120408 | 25 | 25 | 32,0 | 150 | 32,0 | – | |||
| 5697885 | DCLNL2525M16KC06 | CN..160612 | 25 | 25 | 32,0 | 150 | 33,0 | – |
| order | catalogue | gage | HFA | B | F | L1 | LH | B3 | |||
| number | number | insert | (mm)(mm) | (mm) | (mm) | (mm) | (mm) | (mm) | |||
| DCRN 75° | |||||||||||
| right hand | |||||||||||
| 5697904 | DCRNR2525M12KC04 | CN..120408 | 25 | 25 | 32,0 | 150 | 32,0 | 3,34 | |||
| left hand | |||||||||||
| 5697900 | DCRNL2525M12KC04 | CN..120408 | 25 | 25 | 32,0 | 150 | 32,0 | 3,34 |
