Holemaking TOP DRILL S™ (TOP DRILL S — continued) D1 D1 order catalogue diameter diameter L L3 L4 max L5 LS D number number grade (mm) (inch) (mm) (mm) (mm) (mm) (mm) (mm) TDS402A • 5 x D • Through Coolant (continued) 4163077 TDS402A08700 WP20PD 8,700 0.3425 103 61 49 1,5 40 10 4163079 TDS402A08800 WP20PD 8,800 0.3465 103 61 49 1,5 40 10 4163080 TDS402A08900 WP20PD 8,900 0.3504 103 61 49 1,5 40 10 4163081 TDS402A09000 WP20PD 9,000 0.3543 103 61 49 1,5 40 10 4163082 TDS402A09100 WP20PD 9,100 0.3583 103 61 49 1,5 40 10 4163084 TDS402A09200 WP20PD 9,200 0.3622 103 61 49 1,6 40 10 4163085 TDS402A09300 WP20PD 9,300 0.3661 103 61 49 1,6 40 10 4163087 TDS402A09400 WP20PD 9,400 0.3701 103 61 49 1,6 40 10 4163088 TDS402A09500 WP20PD 9,500 0.3740 103 61 49 1,6 40 10 4163090 TDS402A09600 WP20PD 9,600 0.3780 103 61 49 1,6 40 10 4163091 TDS402A09700 WP20PD 9,700 0.3819 103 61 49 1,7 40 10 4163092 TDS402A09800 WP20PD 9,800 0.3858 103 61 49 1,7 40 10 4163093 TDS402A09900 WP20PD 9,900 0.3898 103 61 49 1,7 40 10 4162803 TDS402A10000 WP20PD 10,000 0.3937 103 61 49 1,7 40 10 4162804 TDS402A10100 WP20PD 10,100 0.3976 118 71 56 1,7 45 12 4162805 TDS402A10200 WP20PD 10,200 0.4016 118 71 56 1,7 45 12 4162806 TDS402A10300 WP20PD 10,300 0.4055 118 71 56 1,8 45 12 4162808 TDS402A10400 WP20PD 10,400 0.4094 118 71 56 1,8 45 12 4162809 TDS402A10500 WP20PD 10,500 0.4134 118 71 56 1,8 45 12 4162810 TDS402A10600 WP20PD 10,600 0.4173 118 71 56 1,8 45 12 4162811 TDS402A10700 WP20PD 10,700 0.4213 118 71 56 1,8 45 12 4162813 TDS402A10800 WP20PD 10,800 0.4252 118 71 56 1,8 45 12 4162814 TDS402A10900 WP20PD 10,900 0.4291 118 71 56 1,9 45 12 4162815 TDS402A11000 WP20PD 11,000 0.4331 118 71 56 1,9 45 12 4162818 TDS402A11200 WP20PD 11,200 0.4409 118 71 56 1,9 45 12 4162819 TDS402A11300 WP20PD 11,300 0.4449 118 71 56 1,9 45 12 4162820 TDS402A11400 WP20PD 11,400 0.4488 118 71 56 2,0 45 12 4162821 TDS402A11500 WP20PD 11,500 0.4528 118 71 56 2,0 45 12 4162823 TDS402A11600 WP20PD 11,600 0.4567 118 71 56 2,0 45 12 4162824 TDS402A11700 WP20PD 11,700 0.4606 118 71 56 2,0 45 12 4162825 TDS402A11800 WP20PD 11,800 0.4646 118 71 56 2,0 45 12 4162828 TDS402A12000 WP20PD 12,000 0.4724 118 71 56 2,1 45 12 4162829 TDS402A12100 WP20PD 12,100 0.4764 124 77 60 2,1 45 14 4162830 TDS402A12200 WP20PD 12,200 0.4803 124 77 60 2,1 45 14 4162831 TDS402A12300 WP20PD 12,300 0.4843 124 77 60 2,1 45 14 4162833 TDS402A12400 WP20PD 12,400 0.4882 124 77 60 2,1 45 14 4162834 TDS402A12500 WP20PD 12,500 0.4921 124 77 60 2,1 45 14 4162835 TDS402A12600 WP20PD 12,600 0.4961 124 77 60 2,2 45 14 4162836 TDS402A12700 WP20PD 12,700 0.5000 124 77 60 2,2 45 14 4162837 TDS402A12800 WP20PD 12,800 0.5039 124 77 60 2,2 45 14 4162838 TDS402A12900 WP20PD 12,900 0.5079 124 77 60 2,2 45 14 4162839 TDS402A13000 WP20PD 13,000 0.5118 124 77 60 2,2 45 14 4162841 TDS402A13100 WP20PD 13,100 0.5157 124 77 60 2,3 45 14 4162842 TDS402A13200 WP20PD 13,200 0.5197 124 77 60 2,3 45 14 4162843 TDS402A13300 WP20PD 13,300 0.5236 124 77 60 2,3 45 14 4162844 TDS402A13400 WP20PD 13,400 0.5276 124 77 60 2,3 45 14 4162845 TDS402A13500 WP20PD 13,500 0.5315 124 77 60 2,3 45 14 4162846 TDS402A13600 WP20PD 13,600 0.5354 124 77 60 2,3 45 14 4162847 TDS402A13700 WP20PD 13,700 0.5394 124 77 60 2,4 45 14 4162848 TDS402A13800 WP20PD 13,800 0.5433 124 77 60 2,4 45 14 4162850 TDS402A13900 WP20PD 13,900 0.5472 124 77 60 2,4 45 14 4162851 TDS402A14000 WP20PD 14,000 0.5512 124 77 60 2,4 45 14 4162853 TDS402A14200 WP20PD 14,200 0.5591 133 83 63 2,5 48 16 4162855 TDS402A14300 WP20PD 14,300 0.5630 133 83 63 2,5 48 16 4162857 TDS402A14500 WP20PD 14,500 0.5709 133 83 63 2,5 48 16 4162860 TDS402A14700 WP20PD 14,700 0.5787 133 83 63 2,5 48 16 4162863 TDS402A15000 WP20PD 15,000 0.5906 133 83 63 2,6 48 16 4162876 TDS402A16000 WP20PD 16,000 0.6299 133 83 63 2,8 48 16 4162882 TDS402A16500 WP20PD 16,500 0.6496 143 93 71 2,9 48 18 4162888 TDS402A17000 WP20PD 17,000 0.6693 143 93 71 2,9 48 18 4162894 TDS402A17500 WP20PD 17,500 0.6890 143 93 71 3,0 48 18 4162274 TDS402A18000 WP20PD 18,000 0.7087 143 93 71 3,1 48 18 4162396 TDS402A19000 WP20PD 19,000 0.7480 153 101 77 3,3 50 20 4162407 TDS402A20000 WP20PD 20,000 0.7874 153 101 77 3,5 50 20 widia.com 121 Holemaking
