ST
| P | Steel |
| M | Stainless |
| K | Cast iron |
| N | Non-ferrous |
| S | Superalloys |
| H | Hard materials |
Sintered metal
Designation
CBN
45° 45°
IIS160-45 IIS160-45CBN
: First choice : Second choice Coated CBN
S W1
| IIS160-45 | 2.8 | 9.5 |
| IIS160-45CBN | 2.8 | 9.5 |
: To be supplied on request
OX cartridge (for small depth of cut)
| Cartridge | Insert | Insert screw | Wrench | Adjusting screw | Wrench | Lock screw | Wrench |
| OX04R | TPMX140308L... | CSTB2.5 | T-8D | AS0004-8 | H2 | LS1803.5RH | H2.5 |
| OX32R | TPMX170408L... | CSTB3.5D | T-9D | AS0005-10 | H2.5 | LS1805RH | H3 |
| OX43R | TPMX240512L... | CSTB4M | T-15D | AS0005-15 | H2.5 | LS1806RH | H4 |
| OX63R | TPMX280716L... | CSTB-5 | T-20D | AS0006-15 | H3 | LS1806RH | H4 |
Advanced Technique
An indexable Counterboring Head is the fi rst recommendation for counterboring, but UNIDEX can be used under the conditions below.
1 Small depth of cut (DOC) 2 Depth of cut (DOC) is more than
peripheral insert range Please use OX type for the peripheral cartridge. Large stock removal, such as in counter boring operations, that involves the intermediate cutting
edge may destabilize the drill head movement
during machining. To improve drill stability, install
77° top guide pad as indicated below. 41°
OZ type OX type
Please use a left hand type
insert with a OX cartridge.
Top guide
DOC DOC
| Cartridge | Insert | Cartridge | Insert | ||
| (mm) | (mm) |
| OZ402-04 | 6.4 | TPMX140308R-G | OX04R | 4.0 | TPMX140308L-G |
| OZ402-32 | 7.2 | TPMX170408R-G | OX32R | 4.8 | TPMX170408L-G |
| OZ402-43 | 10.4 | TPMX240512R-G | OX43R | 6.4 | TPMX240512L-G |
| OZ402-63 | 12.0 | TPMX280716R-G | OX63R | 7.6 | TPMX280716L-G |
Maximum DOC of peripheral insert
