| - A single insert has cutting edges for | - Through using helical interpolation |
| both bottom and peripheral surfaces. | method, flat-bottom holes of any |
| Four total cutting edges for better cost | diameter (≥ the cutter diameter +2 mm) |
| per insert. | can be made. |
| - Negative insert with robust design. | - Perfect for counterboring. |
Cutter bodies
Lineup
Shank type: Inserts - EVLX08... (Short type) - LXMU08-MM DC = ø16 mm APMX = 7 mm (ZEFP = 1), 4 mm (ZEFP = 2) EVLX08**L - (Long type) RE = 0.4 mm
| LXMU10-MM | DC = ø16, ø17 mm |
| - EVLX10... (Short type) | |
| APMX = 9 mm (ZEFP = 1), 4 mm (ZEFP = 2) | |
| RE = 0.8 mm | DC = ø20 mm |
| - LXMU12-MM | - EVLX10**L (Long type) |
| APMX = 11 mm (ZEFP = 1), 6 mm (ZEFP = 2) | DC = ø20, ø21 mm |
| RE = 0.8 mm | EVLX12... |
| (Short type) - | |
| Chipbreaker | DC = ø25 mm |
| - MM type: Versatile geometry for low cutting | - EVLX12**L (Long type) |
| forces | DC = ø25, ø26 mm |
| Grades | Modular type: |
| - AH3225: Superior resistance to wear and | - HVLX08... |
| fracture, ideal for steel and stainless steel | DC = ø16 mm |
| - AH8015: Wear-resistant grade ideal for | HVLX10... |
hardened steel and cast iron DC = ø20 mm Scan this QR code - AH120: Excellent edge chipping resistance, to fi nd out more - HVLX12... about this tool!
suited for cast iron DC = ø25 mm
