Minimill Grooving A\
Groove Milling by circular interpolation Groove Milling by circular interpolation
for groove milling general use
for Full Radius
/ >
s


iw
£>
c/>


No of
t max . Fraserschaff
shank face


Designation b ± 0.02 Ds R S tmax Dmin Connector
Teeth

MG 2412- B500T 55 * 5.00 23.7 0.20 5.2 5.5 24.0 12 6 No of
Designation b ± 0.02 Ds R S tmax Dmin Connector
Teeth
2412 - B600T 55 * 6.00 23.7 0.20 5.2 5.5 24.0 12 6
2514- B150T 50 1.50 24.7 5.9 5.0 25.0 14 6
MG 1006 - R075T15 1.20 9.7 0.75 3.5 1.5 10.0 6 3
2514- B200T 50 2.00 24.7 0.20 5.9 5.0 25.0 14 6
1006-R100T15 2.00 9.7 1.00 3.5 1.5 10.0 6 3
2514- B250T 50 2.50 24.7 0.20 5.9 5.0 25.0 14 6
1006 - R125T15 2.50 9.7 1.25 3.5 1.5 10.0 6 3
2514 - B300T 50 3.00 24.7 0.20 5.9 5.0 25.0 14 6
1006- R150T15 3.00 9.7 1.50 3.5 1.5 10.0 6 3
2514- B400T 50 4.00 24.7 0.20 5.9 5.0 25.0 14 6
1206 - R075T25 1.50 11.7 0.75 3.5 2.5 12.0 6 3
2514 - B500T 50* 5.00 24.7 0.20 5.2 5.0 25.0 14 6
1206- R100T25 2.00 11.7 1.00 3.5 2.5 12.0 6 3
2514 B600T 50*
- 6.00 24.7 0.20 5.2 5.0 25.0 14 6
1206 - R125T25 2.50 11.7 1.25 3.5 2.5 12.0 6 3
2512-B150T60 1.50 24.7 5.9 6.0 25.0 12 6
1206- R150T25 3.00 11.7 1.50 3.5 2.5 12.0 6 3
2512 - B200T60 2.00 24.7 0.20 5.9 6.0 25.0 12 6
1608 - R075T35 1.50 15.7 0.75 5.5 3.5 16.0 8 6
2512-B250T60 2.50 24.7 0.20 5.9 6.0 25.0 12 6
1608-R100T35 2.00 15.7 1.00 5.5 3.5 16.0 6 6
2512 - B 300T60 3.00 24.7 0.20 5.9 6.0 25.0 12 6
1608 - R125T 35 2.50 15.7 1.25 5.5 3.5 16.0 8 6
2512 -B400T60 4.00 24.7 0.20 5.9 6.0 25.0 12 6
1809-R075T40 1.50 17.7 0.75 5.5 4.0 18.0 9 6
2614- B200T 55 2.00 25.7 5.9 5.5 26.0 14 6
1809 - R100T40 2.00 17.7 1.00 5.5 4.0 18.0 9 6
2614 - B250T 55 2.50 25.7 0.20 5.9 5.5 26.0 14 6
1809 -R125T40 2.50 17.7 1.25 5.5 4.0 18.0 9 6
2614- B300T 55 3.00 25.7 0.20 5.9 5.5 26.0 14 6
1809- R150T40 3.00 17.7 1.50 5.5 4.0 18.0 9 6
2614 - B400T 55 4.00 25.7 0.20 5.9 5.5 26.0 14 6
2212-R100T45 2.00 21.7 1.00 5.9 4.5 22.0 12 6
2614- B500T 55 * 5.00 25.7 0.20 5.2 5.5 26.0 14 6
2212- R125T45 2.50 21.7 1.25 5.9 4.5 22.0 12 6
2614- B600T 55 * 6.00 25.7 0.20 5.2 5.5 26.0 14 6
2212 -R150T45 3.00 21.7 1.50 5.9 4.5 22.0 12 6
2814- B200T65 2.00 27.7 5.9 6.5 28.0 14 6
2212-R 200T45 4.00 21.7 2.00 5.9 4.5 22.0 12 6
2814- B250T65 2.50 27.7 0.20 5.9 6.5 28.0 14 6
2514- R100T50 2.00 24.7 1.00 5.9 5.0 25.0 14 6
2814 - B 300T65 3.00 27.7 0.20 5.9 6.5 28.0 14 6
2514 - R125T50 2.50 24.7 1.25 5.9 5.0 25.0 14 6
2814- B350T65 3.50 27.7 0.20 5.9 6.5 28.0 14 6
2514- R150T50 3.00 24.7 1.50 5.9 5.0 25.0 14 6
2814 - B400T65 4.00 27.7 0.20 5.9 6.5 28.0 14 6
2514 - R 200T 50 4.00 24.7 2.00 5.9 5.0 25.0 14 6
2814- B500T65 * 5.00 27.7 0.20 5.2 6.5 28.0 14 6
2814- R125T65 2.50 27.7 1.25 5.9 6.5 28.0 14 6
2814 - B600T65 * 6.00 27.7 0.20 5.2 6.5 28.0 14 6
2814 - R150T65 3.00 27.7 1.50 5.9 6.5 28.0 14 6
2812 - B200T75 2.00 27.7 5.9 7.5 28.0 12 6
2814- R200T65 4.00 27.7 2.00 5.9 6.5 28.0 14 6
2812- B250T75 2.50 27.7 0.20 5.9 7.5 28.0 12 6
2812 - B300T75 3.00 27.7 0.20 5.9 7.5 28.0 12 6 Additional sizes available by request.
2812- B350T75 3.50 27.7 0.20 5.9 7.5 28.0 12 6
2812 - B400T75 4.00 27.7 0.20 5.9 7.5 28.0 12 6
The product with has a sub-cutting groove, note compared with the Figl type , that insert will be reduced by
about 1.5 mm after be installed on the holder.
Additional sizes available by request.
