Solid Carbide Twist Drill A\
111


- Manufacturing standard: DIN 6537 - Manufacturing standard: DIN 6537
- Chisel edge grinding: TOOTOOL standard - Chisel edge grinding: TOOTOOL standard
- Tolerance of cutting edge diameter: m 7 - Tolerance of cutting edge diameter: m7
- Chip evacuation flute special designed, - Chip evacuation flute special designed,
easy evacuation easy evacuation


fl I
HA HA
DIN 6535 DIN 6535

mm mm

Dc 3xD 5xD Dc 3xD 5xD
Designation dl 15 Designation dl 15
mm inch Lc 12 II Lc 12 II mm inch Lc 12 II Lc 12 II
..
DCl - 04.800A 6S - C 4.8 6 20 28 66 35 44 82 36 ..
DCl - 06.800A 8 S -C 6.8 8 24 34 79 43 53 91 36
04.900A 6S - C 4.9 6 20 28 66 35 44 82 36 06.900A 8 S -C 6.9 8 24 34 79 43 53 91 36
05.000A 6S - C 5.0 6 20 28 66 35 44 82 36 07.000A 8S-C 7.0 8 24 34 79 43 53 91 36
05.100A 6S - C 5.1 6 20 28 66 35 44 82 36 07.100A 8 S -C 7.1 8 29 41 79 43 53 91 36
05.159A 6S - C 5.159 13/64" 6 20 28 66 35 44 82 36 07.144A 8S-C 7.144 9/ 32" 8 29 41 79 43 53 91 36
05.200A 6S - C 5.2 6 20 28 66 35 44 82 36 07.200A 8 S -C 7.2 8 29 41 79 43 53 91 36
05.300A 6S - C 5.3 6 20 28 66 35 44 82 36 07.300A 8 S -C 7.3 8 29 41 79 43 53 91 36
05.400A 6S - C 5.4 6 20 28 66 35 44 82 36 07.400A 8 S -C 7.4 8 29 41 79 43 53 91 36
05.500A 6S - C 5.5 6 20 28 66 35 44 82 36 07.500A 8 S -C 7.5 8 29 41 79 43 53 91 36
05.550A 6S - C 5.55 6 20 28 66 35 44 82 36 07.541A 8 S -C 7.541 8 29 41 79 43 53 91 36
05.556A 6S - C 5.556 7/ 32" 6 20 28 66 35 44 82 36 07.550A 8 S -C 7.55 19/64" 8 29 41 79 43 53 91 36
05.600A 6S - C 5.6 6 20 28 66 35 44 82 36 07.600A 8 S -C 7.6 8 29 41 79 43 53 91 36
05.700A 6S - C 5.7 6 20 28 66 35 44 82 36 07.700A 8S-C 7.7 8 29 41 79 43 53 91 36
05.800A 6S - C 5.8 6 20 28 66 35 44 82 36 07.800A 8 S -C 7.8 8 29 41 79 43 53 91 36
05.900A 6S - C 5.9 6 20 28 66 35 44 82 36 07.900A 8S-C 7.9 8 29 41 79 43 53 91 36
05.953A 6S - C 5.953 15 /64" 6 20 28 66 35 44 82 36 07.938A 8 S -C 7.938 5/16" 8 29 41 79 43 53 91 36
06.000A 6S - C 6.0 6 20 28 66 35 44 82 36 08.000A 8 S -C 8.0 8 29 41 79 43 53 91 36
06.100A 8S - C 6.1 8 24 34 79 43 53 91 36 08.100A10S - C 8.1 10 35 47 89 49 61 103 40
06.200A 8S - C 6.2 8 24 34 79 43 53 91 36 08.200A10S - C 8.2 10 35 47 89 49 61 103 40
06.300A 8S - C 6.3 8 24 34 79 43 53 91 36 08.300A10S - C 8.3 10 35 47 89 49 61 103 40
06.350A 8S - C 6.35 VA" 8 24 34 79 43 53 91 36 08.344A10S - C 8.344 21/64" 10 35 47 89 49 61 103 40
06.400A 8S - C 6.4 8 24 34 79 43 53 91 36 08.400A10S - C 8.4 10 35 47 89 49 61 103 40
06.500A 8S - C 6.5 8 24 34 79 43 53 91 36 08.500A10S-C 8.5 10 35 47 89 49 61 103 40
06.600A 8S - C 6.6 8 24 34 79 43 53 91 36 08.600A10S - C 8.6 10 35 47 89 49 61 103 40
06.700A 8S - C 6.7 8 24 34 79 43 53 91 36 08.700A10S - C 8.7 10 35 47 89 49 61 103 40
06.747A 8S - C 6.747 17/64" 8 24 34 79 43 53 91 36 08.731A10S - C 8.731 11/ 32 " 10 35 47 89 49 61 103 40
