HD Type Replaceable Head Drill A\ # HD Type Replaceable Head Drill 5 x D HD Type Replaceable Head Drill 7 x D d4 d4 i IDcILci11 dit Lc a1 Idit m- 14 15 14 15 mm mm Size Spare Parts Size Spare Parts Designation Dc Lc 14 15 dl d4 Seat size Designation Dc Lc 14 15 dl d4 Seat size y HD XD 05 -120- XP16 12 62 92 48 16 20 A FS3011D T-10S HD XD 07-120-XP16 12 86 116 48 16 20 A FS3011D T-10S 05 -130- XP16 13 67 98 48 16 20 A FS3012D T-10S 07-130-XP16 13 93 124 48 16 20 A FS3012D T-10S 05 -140- XP16 14 73 104 48 16 20 B FS3013D T-10S 07-140-XP16 14 101 132 48 16 20 B FS3013D T-10S 05 -150-XP16 15 78 110 48 16 20 B FS3013D T-10S 07-150-XP16 15 108 140 48 16 20 B FS3013D T-10S 05 -160- XP 20 16 83 116 50 20 25 C FS3514D T-15S 07-160-XP20 16 115 148 50 20 25 C FS3514D T-15S 05 -170- XP 20 17 88 122 50 20 25 C FS3514D T-15S 07 -170- XP20 17 122 156 50 20 25 C FS3514D T-15S 05 -180-XP20 18 93 128 50 20 25 D FS3515D T-15S 07-180-XP20 18 133 164 50 20 25 D FS3515D T-15S 05 -190-XP20 19 98 134 50 20 25 D FS3516D T-15S 07-190-XP20 19 136 172 50 20 25 D FS3516D T-15S 05 - 200- XP20 20 104 140 50 20 25 E FS4018D T-15S 07-200-XP20 20 144 180 50 20 25 E FS4018D T-15S 05 - 210- XP20 21 109 146 50 20 25 E FS4018D T-15S 07-210-XP20 21 151 188 50 20 25 E FS4018D T-15S 05 - 220-XP25 22 114 153 56 25 32 F FS5019D T-20S 07-220-XP25 22 158 197 56 25 32 F FS5019D T-20S 05 - 230- XP25 23 119 159 56 25 32 F FS5019D T-20S 07-230-XP25 23 165 205 56 25 32 F FS5019D T-20S 05 - 240- XP 25 24 124 165 56 25 32 G FS5021D T-20S 07-240-XP25 24 172 213 56 25 32 G FS5021D T-20S 05 - 250-XP25 25 130 171 56 25 32 G FS5021D T-20S 07-250-XP25 25 180 221 56 25 32 G FS5021D T-20S 05 - 260- XP 25 26 135 177 56 25 32 H FS6023D T-25S 07-260-XP25 26 187 229 56 25 32 H FS6023D T-25S 05 - 270-XP25 27 140 183 56 25 32 H FS6023D T-25S 07-270-XP25 27 194 237 56 25 32 H FS6023D T-25S 05 - 280-XP32 28 145 190 60 32 40 J FS6025D T-25S 07-280-XP32 28 201 246 60 32 40 J FS6025D T-25S 05 - 290-XP32 29 150 196 60 32 40 J FS6025D T-25S 07-290-XP32 29 208 254 60 32 40 J FS6025D T-25S 05 - 300- XP32 30 155 202 60 32 40 K FS6028D T-25S 07-300-XP32 30 215 262 60 32 40 K FS6028D T-25S 05 - 310- XP32 31 161 208 60 32 40 K FS6028D T-25S 07-310-XP32 31 223 270 60 32 40 K FS6028D T-25S 05 - 320-XP40 32 166 213 70 40 50 M FS6028D T-25S 07-320-XP40 32 230 277 70 40 50 M FS6028D T-25S 05 - 330- XP40 33 171 218 70 40 50 M FS6030D T-25S 07-330-XP40 33 237 285 70 40 50 M FS6030D T-25S 05 - 340- XP40 34 176 223 70 40 50 N FS6030D T-25S 07-340-XP40 34 245 293 70 40 50 N FS6030D T-25S 05 - 350-XP40 35 181 231 70 40 50 N FS6030D T-25S 07-350-XP40 35 252 300 70 40 50 N FS6030D T-25S 05 - 360- XP40 36 186 236 70 40 50 P FS6033D T-25S 07-360-XP40 36 260 308 70 40 50 P FS6033D T-25S 05 - 370-XP40 37 191 241 70 40 50 P FS6033D T-25S 07-370-XP40 37 267 316 70 40 50 P FS6033D T-25S 05 - 380-XP40 38 196 246 70 40 50 Q FS6035D T-25S 07-380-XP40 38 274 323 70 40 50 Q FS6035D T-25S 05 - 390-XP40 39 201 251 70 40 50 Q FS6035D T-25S 07-390-XP40 39 281 330 70 40 50 Q FS6035D T-25S 741 742
