Technical Information for Multi- function system A\
USERS GUIDE TCMT ( Mulit -Turn) - 2.25xD
Offset (Diameter compensation)
0d
Machined
Designation
diameter (mm)
0Dmin(mm) 0Dmax(mm)
n
L
0D min 0D max TCMT -08 8 7.86 8.35

V
>V TCMT-10
TCMT -12
10
12
9.82
11.82
10.60
12.60
TCMT-14 14 13.80 14.60
TCMT -16 16 15.76 16.50
mm
TCMT - 20 20 19.80 20.60
TCMT -25 25 24.80 25.80 Spare parts
Size
TCMT - 32 32 31.80 33.00
Designation Inserts
0D 0d l 12 L
TCMT 08 R- 2.25D-N12 - XC 8 12 18.0 38 60.0 XCMT040104 L0455 SSTX1.8-2.7P TPF -06
10R- 2.25D-N12 - XC 10 12 22.5 42 69.5 XCMT050204 L0420SSTX 2.0-2.8 P TPF -06
12R - 2.25D-N16- XC 12 16 27.0 45 78.0 XCMT060204 L0560SSTX 2.2- 3.0P TPF - 06
14R - 2.25D-N16- XC 14 16 31.5 45 83.5 XCMT070304 L0655 SSTX 2.5 - 3.6P TPF - 08
16R - 2.25D-N16 - XC 16 16 36.0 50 94.0 XCMT080304 L0750SSTX3.0 -4.0P TPF - 08
20R- 2.25D- N20- XC 20 20 45.0 56 111.0 XCMT10T 304 L0960SSTX3.5 - 5.5 P TPF -15
25 R - 2.25D-N25 - XC 25 25 56.5 61 130.0 XCMT130404 L1060SSTX4.5 - 5.7P TPF -20
32R - 2.25D-N32 - XC 32 32 72.0 74 160.0 XCMT170508 L1060SSTX4.5 - 5.7 P TPF - 20


: 0d

B
L


mm
Spare parts
Size
Designation Inserts
0D 0d t L
TCMT 08 R - 3 D - N12- XC 8 12 24 70 XCMT040104 L0455 SSTX 1.8- 2.7 P TPF - 06
10R 3D N12- XC
- - 10 12 30 75 XCMT050204 L0420SSTX 2.0- 2.8 P TPF - 06
12R - 3D - N16 - XC 12 16 36 90 XCMT060204 L0560SSTX 2.2- 3.0P TPF - 06
14R - 3D - N16- XC 14 16 42 95 XCMT070304 L0655 SSTX 2.5 - 3.6P TPF -08
16 R - 3 D - N16 - XC 16 16 48 100 XCMT080304 L0750SSTX 3.0-4.0P TPF - 08
20 R - 3 D - N 20 - XC 20 20 60 130 XCMT10T304 L0960SSTX3.5 - 5.5 P TPF -15
25 R - 3D -N25 - XC 25 25 75 150 XCMT130404 L1060SSTX 4.5 - 5.7 P TPF - 20
32R - 3 D - N 32- XC 32 32 96 185 XCMT170508 L1060SSTX4.5 - 5.7 P TPF - 20


733 734
